Key Features: Quantum X FaroArm® Series

Multiple Working Volumes

Meet the needs of different applications with working volumes of 2.0m, 2.5m, 3.0m, 3.5m and 4.0m for each of the performance models.

Kinematic Mount Flexibility

Enhance speed and accessibility with a kinematic mount that allows LLPs and probes to be interchanged seamlessly without the need for compensation after each exchange.

Internal Counterbalancing

Operate with a single hand to limit fatigue and avoid damaging the FaroArm when a joint is unable to hold the weight.

Ergonomic Design and Portable

Transport, set up and operate FaroArms with ease and comfort.

Exclusive FARO Quantum X 8-Axis Max Integration

Quickly measure all sides of a part without repositioning. Simply rotate the part on the 8-Axis Max rotary worktable.

Compliance

Meet rigorous ISO 10360 performance standards.

Temperature and Overload Sensors

Ensure continuous, optimum performance.

Powerful Software Solutions

Easily integrate FaroArms with FARO CAM2 or with most of the 3rd party inspection software.

Extended Battery Use Option

Operate without cables with the two, hot-swappable batteries.

High-speed Wireless Operation

Connect with included Bluetooth or Wi-Fi.

Rugged Design

Use FaroArms even in the most challenging measurement environments.

Family of Laser Line Probes (LLPs)

Achieve high-speed point cloud capture, high accuracy or a blend of both with LLPs, each hot swappable and purpose built.

Continuous Light Rectification (CLR) Technology

Scan dark, reflective or translucent surfaces with any LLP.

Smart Probe Capability

Quickly and easily change FARO probes without compensation.

Specifications: Quantum X FaroArm® Series

The Quantum X FaroArm solution portfolio sets the benchmark in the portable measurement market.

Highest Probing Accuracy

Up to 23µm volumetric accuracy for 2.0m arms and up to 63µm accuracy for the 4.0m arm model.

High-standard non-contact scanning performance

30µm accuracy at an up to 1.2 million points per second scan rate and an up to 15µm point spacing for high details.

Click here below to download the Brochure for the complete specifications
