Fluke ProSim 8 / ProSim 8P Patient Simulator

• 8-in-1 multifunction patient simulator is a combination ECG simulator, fetal simulator, arrhythmia simulator, respiration simulator, temperature simulator, IBP simulator, cardiac output simulator, cardiac catheterization simulator, NIBP simulator
• SpO2 simulator to test Rainbow multi-wavelength waveforms (with optional ProSim SpO2 Test Module)
• Stay-connected ECG posts for easy/secure ECG snap and lead connections
• Static pressure linearity testing
• Improved manometer accuracy with the ProSim 8P
• Repeatable NIBP simulation for dynamic pressure repeatability testing
• Physiologically synchronized pulses across all parameters
• Barcode scanning and direct data capture and printing functionality
• Onboard, patient pre-sets and auto sequences for fast/easy testing
• Multi-language user interface offers choice of language selection
• The device includes an external, long-life battery that allows for more flexible charging options
• Optional OneQA Workflow Automation Software offers customizable procedures/checklists and automated data capture/storage

General Specifications

Detailed Signal Specifications

1. ECG & Arrhythmia

• Lead II amplitude: 0.05 – 5.0 mV (steps) with ±2% accuracy (+0.05 mV for low levels)

• Other leads proportional (e.g., Lead I = 70%, V4 = 120%)

• Heart rate: 10 – 360 BPM, ±1%; QRS: 80 ms adult or 40 ms pediatric

• ST elevation: –0.8 to +0.8 mV

• Pacemaker waveforms: amplitude 0–700 mV, width 0.1–2 ms, ±5%

• Arrhythmia presets: AFib, flutter, PVCs, tachycardias, blocks, ALS rhythms etc.

• ECG performance modes: waves and artifacts for testing dev.—e.g., sine, square, triangular, artifact injections

2. Fetal/Maternal ECG & IUP

• Fetal HR: fixed 60–240 BPM or IUP-synchronised; IUP waveforms with early/late decel. and accelerations, 0–90 mmHg over 90s

3. Invasive BP (IBP)

• 2 isolated channels; DC–5000 Hz exciter input; ±(1% + 1 mmHg) accuracy

• Pressure range: –10 to +300 mmHg (static); dynamic curves: arterial, ventricular, PA, etc.

4. Respiration

• Rate: 0 or 10 – 150 BrPM; waveforms: normal/ventilated; impedance baseline 500–2000 Ω

• Amplitude accuracy ±(5% + 0.1 Ω); includes apnea simulation

5. Temperature

• 30.0–42.0 °C (0.5 °C steps); high‑accuracy presets (0/24/25/37/40 °C) with ±0.4 °C (std), ±0.1 °C (high)

6. Cardiac Output

• Simulates thermodilution with 0 °C or 24 °C injectate; 2.5–10 L/min ±7.5% accuracy

7. Non-Invasive BP (NIBP)

• Range: 10–400 mmHg; ProSim 8 accuracy ±(0.5% + 0.5 mmHg), 8P improved accuracy

• Pre-set BP simulations for adult/neonatal; pulse & leak test supported

8. SpO₂ (optional module)

• Range: 30%–100%; ±1–7% depending on level and UUT's R-curve; heart rate 30–300 BPM; includes artifact simulation and Rainbow compatibility.

Dimensions & Environmental

• Physical: 14.5 × 30.2 × 8.6 cm; 1.81 kg

• Battery: lasts ~9 hrs; charges via AC/DC

• Operating temp: specified accuracy conditions (e.g., NIBP accuracy within 10–30 °C)

Click Here for Data Sheet

Accessories & Ordering

• Core accessories: manuals, battery pack, USB cable, IBP cable, NIBP mandrel set, adaptors, carrying case, power supply

• Optional modules/cables: SpO₂ Test Module, Rainbow Cable, CI‑3 Cardiac Output Box, NIBP test chamber, software plugins, various brand-specific cable kits

• Multiple regional part numbers (AU, BR, JP, UK, SCHUKO) available
