Kyoritsu KEW 1021R Digital Multimeters has a large display with 6000 counts and a Backlight. This meter is more than accurate, rugged and reliable.
This Meter has safety Standard IEC 61010-1 CAT IV 300V / CAT III 600V. We provide the best tools very affordable price. Not only do we provide the best tools but also we support all the time to our customers.
Kyoritsu KEW 1021R Digital Multimeter great tool that offers exceptional accuracy and reliability. Shop now at Tools Bangladesh for the best price in Bangladesh. Tools Bangladesh ensures the availability of high-quality, reliable multimeters at affordable prices, delivering the best tools nationwide for both professionals and hobbyists.
Key Features: Kyoritsu KEW 1021R Digital Multimeters
• Elegant and easy-to-use cabinet
• Large display with 6000 counts and Backlight
• Enhanced current measuring function using an external clamp sensor
• Two detachable holders, flat and wing type
• Accurate reading with True RMS
• Safety Standard IEC 61010-1 CAT IV 300V / CAT III 600V
Specifications: Kyoritsu KEW 1021R Digital Multimeters
| DC V |
6.000/60.00/600.0V (auto range)
±0.5%rdg ±3dgt |
| DC mV |
600.0mV
±1.5%rdg ±3dgt |
| DC Clamp Sensor |
60.00/200.0A (auto range)
±1.5%rdg ±3dgt + Sensor accuracy |
| AC V |
6.000/60.00/600.0V (auto range)
±1.0%rdg ±3dgt [40 - 500Hz] |
| AC mV |
600.0mV
±2.0%rdg ±3dgt [40 - 500Hz] |
| AC Clamp Sensor |
60.00/200.0A (auto range)
±2.0%rdg ±3dgt + Sensor accuracy [40 - 500Hz] |
| DC A |
6.000/10.00A (auto range)
±1.5%rdg ±3dgt |
| AC A |
6.000/10.00A (auto range)
±1.5%rdg ±3dgt[45 - 500Hz] |
| Ω |
600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (auto range)
±0.5%rdg ±4dgt (600Ω),
±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ)
±1.5%rdg ±3dgt (40MΩ) |
| Continuity buzzer |
600Ω (Buzzer sounds below 90Ω) |
| Diode test |
Open-loop voltage: < 3.0V |
| Capacitance |
60.00/600.0nF/6.000/60.00/600.0/1000µF
±2.0%rdg ±5dgt (60/600nF)
±5.0%rdg ±5dgt (6/60/600/1000µF) |
| Frequency |
ACV 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt
ACA 99.99/999.9Hz/9.999kHz ±0.1%rdg ±3dgt |
| DUTY |
10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz] |
| Applicable standards |
IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V
IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS) |
| Power source |
R03 (1.5V) × 2 |
| Dimensions |
155(L) × 75(W) × 40(D)mm |
| Weight |
250g Approx. (including batteries) |
Includes: Kyoritsu KEW 1021R Digital Multimeters
- Kyoritsu KEW 1021R Digital Multimeters
Accessories: Kyoritsu KEW 1021R Digital Multimeters
| Included Accessories |
Wing-type holder, Flat-type holder, 7066A (Test leads),
8919 (Ceramic fuse [10A/600V]) × 1 (included),
9097 (Carrying case), R03 × 2, Instruction manual |
| Optional Accessories |
7234 (Alligator clip), 8161 (AC clamp adaptor)
8115 (AC/DC clamp sensor), 9189 (Magnet hanger strap) |
