The UT118C Pen-type meter is a lightweight and durable device that boasts True RMS measurement capability, allowing for accurate readings. With the ability to measure voltage up to AC/DC 600, a wide resistance and capacitance range, and gold-plated special-tip test leads for versatility and safe operation (CAT III 600V & CAT IV 300V), it is an excellent and cost-effective choice for residential appliance repair and DIY enthusiasts.
Features of UT118C Pen-type meter
Certifications (UT118C series only): CE, cETLus, RoHS
● True RMS
● Two-color mold injection
● Display 6000
● CAT III 600V/CAT IV 300V
● 600V DC/AC voltage measurement
● Large resistance measurement: 60MΩ
● Large capacitance measurement: 60mF
● Diode/on/off/resistor automatic identification
● Two-step adjustment of nib length
● Gold-plated special-tip test leads, hardened phosphor bronze
● CE (EMC, LVD), ROHS
Specifications
| Technical Specifications |
|
| DC voltage (V) |
6.000V/60.00V/600.0V |
±（1％＋3） |
| AC voltage (V) |
6.000V/60.00V/600.0V |
±（1％＋4） |
| Resistance |
600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ |
±(1%+3) |
| 6.000MΩ |
±(1.5%+5) |
| 60.00MΩ |
±(2.5%+5) |
| Capacitance |
600.0nF/6.000uF/60.00uF/600.0uF |
±（3.5%+8) |
| 6.000mF |
±（5.0%+9) |
| 60.00mF |
±（10.0%+9) |
| Frequency |
99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz |
±(0.01%+5) |
| Features |
| Display count |
6000 |
| Duty cycle |
0.1% to 99.9% |
| NCV/LIVE test |
√ |
| True RMS |
√ |
| Diode |
√ |
| Continuity |
√ |
| Resistance |
√ |
| Auto range |
√ |
| Screen |
HTN LCD 36*15mm |
| Auto power off |
√ |
| Flash light |
√ |
| Indicator |
Dual color |
| Battery |
AAA*1 |
| Category rating |
CAT IV 300V; CAT III 600V |
| Certificates |
CE/cETLus/ROHS |
| General Characteristics |
| Power supply |
AAA*1 |
| Product dimension |
182.5mm x 38.0mm x 38.5mm |
| Product color |
Gray + Red |
| Accessories |
User manual 1pcs, 1.5V AAA battery 1pcs |
