Name: Kyoritsu KEW 1020R Digital Multimeters
Brand: Kyoritsu
Availability: InStock

Shop	:
Product ID	:	1153
Brand	:	Kyoritsu
Availability	:	In Stock
Price BDT	:	0.00 Taka
Reviews	:
Share	:

Add To Cart

Customer Support
+8801965656380
Cash One Delivery
Pay after getting the product on hand
Warranty
1 Year warranty by manufacturer
Secured Payment Method
Your cart is always secure to shop
Easy Return Policy
7 days return without physical defect.

Kyoritsu KEW 1020R Digital Multimeters is the best and accurate measurement tool. Kyoritsu Kew 1020R Digital Multimeters Dc V 1000V New ix. Kyoritsu electric meter (KYORITSU) card-type digital multimeter KEW 1019R.

Key Features: Kyoritsu KEW 1020R Digital Multimeters

• Large display with 6000 counts and Backlight
• True-RMS
• MIN/MAX function
• Rugged and reliable
• Clamp sensor mode
• IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V

Specifications: Kyoritsu KEW 1020R Digital Multimeters

DC V	6.000/60.00/600.0/1000V (auto range) ±0.5%rdg ±3dgt (6/60/600V) ±0.8%rdg ±3dgt (1000V)
DC mV	600.0mV ±1.5%rdg ±3dgt
DC Clamp Sensor	60.00/200.0A (auto range) ±1.5%rdg ±3dgt + Sensor accuracy
AC V	6.000/60.00/600.0/1000V (auto range) ±1.0%rdg ±3dgt [40 - 500Hz] (6/60/600V) ±1.3%rdg ±3dgt [40 - 500Hz] (1000V)
AC mV	600.0mV ±2.0%rdg ±3dgt [40 - 500Hz]
AC Clamp Sensor	60.00/200.0A (auto range) ±2.0%rdg ±3dgt + Sensor accuracy [40 - 500Hz]
Ω	600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (auto range) ±0.5%rdg ±4dgt (600Ω) ±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ) ±1.5%rdg ±3dgt (40MΩ)
Continuity buzzer	600Ω (Buzzer sounds below 90Ω)
Diode test	Open-loop voltage: < 3.0V
Capacitance	60.00/600.0nF/6.000/60.00/600.0/1000µF ±2.0%rdg ±5dgt (60/600nF) ±5.0%rdg ±5dgt (6/60/600/1000µF)
Frequency	99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt
DUTY	10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz]
Applicable standards	IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS)
Power source	R03 (1.5V) × 2
Dimensions	155(L) × 75(W) × 40(D)mm
Weight	250g Approx. (including batteries)
Included Accessories	Wing-type holder 7066A (Test leads) R03 × 2, Instruction manual
Optional Accessories	7234 (Alligator clips) 8161 (AC Clamp sensor) 8115 (AC/DC Clamp sensor)
