Keyoritsu KEW 1011 Digital Multimeters is a rugged reliable and 100% productive measurement tool. KEW 1011 can be supple max. 700C. In order to skirmish progressive than 300C, engross use a K-type temperature study to hand in the market. Applicable standards. IEC 61010-1 CAT III 300V Pollution degree 2.

Key Features: Keyoritsu KEW 1011 Digital Multimeters

• Temperature measurement, selectable for ºC and ºF
• 6040 counts with Bar Graph display
• MIN/MAX function enables to record min & max value
• REL(relative value) function to indicate the measurement variation

Specifications: Keyoritsu KEW 1011 Digital Multimeters

DC V	600.0mV/6.000/60.00/600.0/600V (Input Impedance: 10MΩ, 100MΩ only 600mV) ±0.5%±2dgt (600.0mV/6.000/60.00/600.0V) ±0.8%±3dgt (600V)
AC V	6.000/60.00/600.0/600V (Input Impedance: 10MΩ) ±1.0%±3dgt (6.000/60.00/600.0V)±1.5%±3dgt (600V)
DC A	600/6000µA/60/600mA/6/10A ±1.2%±3dgt (600/6000µA/60/600mA) ±2.0%±5dgt (6/10A)
AC A	600/6000µA/60/600mA/6/10A ±1.5%±4dgt (600/6000µA/60/600mA) ±2.2%±5dgt (6/10A)
Ω	600Ω/6/60/600kΩ/6/60MΩ ±1.0%±2dgt (600Ω/6/60/600kΩ/6MΩ) ±2.0%±3dgt (60MΩ)
Continuity buzzer	0 - 600Ω (Buzzer sounds below 100Ω)
Diode test	2.8V Release Voltage:Approx. 0.4mA Test Current
Capacitance	40/400nF/4/40/400/4000µF
Frequency	10/100/1000Hz/10/100/1000kHz/10MHz
DUTY	0.1 - 99.9% (Pulse width/Pulse period) ±2.0%±2dgt (- 10kHz)
Temperature	-50 - 300ºC (-58 - 572ºF) (with the use of Temperature probe 8216) Note: KEW 1011 can measure max. 700ºC In order to measure over 300ºC, please use a K-type temperature probe available in the market.
Applicable standards	IEC 61010-1 CAT III 300V Pollution degree 2 IEC 61010-1 CAT II 600V Pollution degree 2 IEC 61010-031 IEC 61326
Display	6040 Counts
Power source	R6 (1.5V) × 2 (Auto-power-OFF within 15 minutes)
Dimensions	161(L) × 82(W) × 50(D)mm
Weight	Approx. 280g
Included Accessories	7066A (Test leads) 8216 (K-type Temperature probe) 0.8A/600V (Ceramic Fuse) × 1built-in 10A/600V (Ceramic Fuse) × 1built-in R6 × 2Instruction Manual
Optional Accessories	7234 (Crocodile clip test lead) 9095 (Carrying case)
