EXTECH MM560A MultiMaster® High-Accuracy Multimeter

The EXTECH MM560A is a high-precision digital multimeter designed for professionals requiring accurate measurements in demanding environments. It features a 50,000-count (500,000 for DC voltage and frequency) backlit LCD display with a bargraph, offering high resolution up to 1µV, 0.0001Hz, 0.01Ω, and 0.01µA. The multimeter supports a wide range of functions, including AC/DC voltage and current (up to 10A), resistance, capacitance, frequency, duty cycle, diode testing, and 4–20mA process current measurements. Its True RMS capability ensures accurate readings of non-sinusoidal waveforms. The MM560A also includes features like max/min recording, auto-ranging, relative & hold functions, and a peak function to capture transient pulses. Built for durability, it comes with test leads, a protective holster with a stand, and a 9V battery. This multimeter is ideal for engineers and technicians in Bangladesh seeking reliable and precise measurement tools. Discover the EXTECH MM560A MultiMaster® High-Accuracy Multimeter in Bangladesh, learn about the EXTECH 60120B Mini pH Electrode in Bangladesh, and explore top-rated Digital Multimeter options for precise diagnostics.

Extech MM560A: MultiMaster® High-Accuracy Multimeter

True RMS Multimeter with 50,000/500,000 count LCD

Features:

Full range multimeter functions with 0.03% basic DCV accuracy and up to 20kHz True RMS ACV bandwidth
50,000 count (500,000 for DCV and Hz) backlit LCD display with bargraph
Special True RMS combination AC+DC function for measurements of rectified AC (non-symmetrical) voltage & current waveforms
Filtered frequency function with adjustable trigger levels for variable speed motor drives and high voltage applications
AC/DC current to 10A with 0.01µA resolution
4 to 20mA, displayed as 0-100% for process current measurements
Capacitance, Frequency, Resistance, Continuity, Duty cycle and Diode tests with 600V input protection on all functions (1000V on Voltage)
High resolution to 1µV, 0.0001Hz, 0.01Ohm, 0.01µA and 0.1°
Max/Min recording with autoranging, Auto Power off, Relative & Hold, Peak function captures transient pulses
Optional Windows® compatible PC communication software and optically isolated cable
Complete with test leads, protective holster with stand and 9V battery

N/A

N/A

N/A

EXTECH MM560A MultiMaster® High-Accuracy Multimeter

The EXTECH MM560A is a high-precision digital multimeter designed for professionals requiring accurate measurements in demanding environments. It features a 50,000-count (500,000 for DC voltage and frequency) backlit LCD display with a bargraph, offering high resolution up to 1µV, 0.0001Hz, 0.01Ω, and 0.01µA. The multimeter supports a wide range of functions, including AC/DC voltage and current (up to 10A), resistance, capacitance, frequency, duty cycle, diode testing, and 4–20mA process current measurements. Its True RMS capability ensures accurate readings of non-sinusoidal waveforms. The MM560A also includes features like max/min recording, auto-ranging, relative & hold functions, and a peak function to capture transient pulses. Built for durability, it comes with test leads, a protective holster with a stand, and a 9V battery. This multimeter is ideal for engineers and technicians in Bangladesh seeking reliable and precise measurement tools. Discover the EXTECH MM560A MultiMaster® High-Accuracy Multimeter in Bangladesh, learn about the EXTECH 60120B Mini pH Electrode in Bangladesh, and explore top-rated Digital Multimeter options for precise diagnostics.

Extech MM560A: MultiMaster® High-Accuracy Multimeter

True RMS Multimeter with 50,000/500,000 count LCD

Features:

Full range multimeter functions with 0.03% basic DCV accuracy and up to 20kHz True RMS ACV bandwidth
50,000 count (500,000 for DCV and Hz) backlit LCD display with bargraph
Special True RMS combination AC+DC function for measurements of rectified AC (non-symmetrical) voltage & current waveforms
Filtered frequency function with adjustable trigger levels for variable speed motor drives and high voltage applications
AC/DC current to 10A with 0.01µA resolution
4 to 20mA, displayed as 0-100% for process current measurements
Capacitance, Frequency, Resistance, Continuity, Duty cycle and Diode tests with 600V input protection on all functions (1000V on Voltage)
High resolution to 1µV, 0.0001Hz, 0.01Ohm, 0.01µA and 0.1°
Max/Min recording with autoranging, Auto Power off, Relative & Hold, Peak function captures transient pulses
Optional Windows® compatible PC communication software and optically isolated cable
Complete with test leads, protective holster with stand and 9V battery
