KYORITSU KEW 6516 MULTI FUNCTION INSTALLATION TESTER

Home / Kyoritsu
Thumbnail
Shop : Tools Bangladesh
Product ID : 3766
Brand : Kyoritsu
Availability : In Stock (1)
Price BDT :
৳ 0
Reviews : (0)
Share :
Order Now on WhatsApp Request Quote

  • Customer Support

    +8801965656380

  • Cash On Delivery

    Pay after getting the product on hand

  • Warranty

    1 Year warranty by manufacturer

  • Secured Payment Method

    Your cart is always secure to shop

  • Easy Return Policy

    24 hours return without physical defect.

KYORITSU KEW 6516 MULTI FUNCTION INSTALLATION TESTER:

The KYORITSU KEW 6516 is a reliable multi-function installation tester built for comprehensive electrical testing, including insulation resistance, loop impedance, and continuity tests. Designed for ease of use, it features a clear display, and straightforward controls, and ensures accurate measurements that comply with electrical safety standards, making it an essential tool for professionals in electrical installation and maintenance.

Are you trying to find a good, Insulation Tester? Yes, this is the perfect moment and place for you. Tools Bangladesh is offering testing supplies and tools in Bangladesh. As a result, You could be able to purchase the desired tool from us in Bangladesh with the most affordable price and delivery options.



Key Features:

A lot of Testing Power is in the hands of Electrical Installation Professionals!

  • DISPLAY
    Color LCD 3.5 inches dot matrix.
  • ATT
    Anti-Trip Technology (with 2 & 3 wire) for no trip LOOP L-PE testing on all RCDs.
    With 2 wires only, very useful in case of no Neutral (i.e. 3-phase motor lines).
  • LOOP
    ・High test current range of 2Ω with 0.001Ω resolution.
    ・Zs Limit compares the values required by the Electrical Installations Standard with measured results.
  • RCD
    ・Type AC, A, F, B(General & Selective), EV and Variable RCDs.
    ・Single and Autotest, Ramp test and Contact voltage.
  • EARTH
    Earth resistance test 2 and 3 wires with all accessories included.
  • INSULATION
    Resistance test 100, 250, 500 & 1000V with auto discharge voltage.
  • CONTINUITY
    Continuity test at 200mA or 15mA with a selectable buzzer for fast judgment.
  • PHASE ROTATION
    On 3-phase lines with a clear indication of the sequence on the display.
  • VOLTS
    TRMS Voltage measurements 2-600V, Mains Frequency.
  • HELP
    The display shows how to connect the instrument according to the function selected.
  • SPD
    Surge Protection Device test, for SPD that uses varistor.
  • PAT
    Portable Appliance Tester function, for Insulation and Protective conductor resistance test
  • SAFETY
    IEC 61010-1 CAT Ⅳ 300V / CAT Ⅲ 600V, IEC 61557-1,2,3,4,5,6,7,10.

Specifications:

Insulation resistance SPD
(Varistor)
Test voltage 100V 250V 500V 1000V Max.1000V
Measuring ranges 2.000/20.00/200.0MΩ
(Auto-ranging)		 20.00/200.0/
1000MΩ
(Auto-ranging)		 20.00/200.0/
2000MΩ
(Auto-ranging)		 0-1049V
(goes up by 1V)
Accuracy ±2%rdg±6dgt
(2.000/20.00MΩ)
±5%rdg±6dgt
(200.0MΩ)		 ±2%rdg±6dgt
(20.00/200.0MΩ)
±5%rdg±6dgt
(1000MΩ)		 ±2%rdg±6dgt
(20.00/200.0MΩ)
±5%rdg±6dgt
(2000MΩ)		 ±5%rdg±5dgt
Rated current 1.0-1.2mA
@0.1MΩ		 1.0-1.2mA
@0.25MΩ		 1.0-1.2mA
@0.5MΩ		 1.0-1.2mA
@1MΩ		 ‐
Output short circuit current 1.5mA max ‐
Loop impedance
Function LOOP ATT LOOP HIGH
L-PE/L-N
(3wire)		 L-PE
(2wire)		 L-PE
(0.01ΩRes)		 L-PE
(0.001ΩRes)
High test current
(25A)		 L-N/L-L
Rated voltage 100-260V
(50/60Hz)		 48-260V
(50/60Hz)		 48-260V
(50/60Hz)		 100-260V
(50/60Hz)		 48-500V
(50/60Hz)
Impedance range 20.00/200.0/2000Ω
 (Auto-ranging)		 20.00/200.0/2000Ω
(Auto-ranging)		 2.000Ω 20.00Ω
Accuracy ±3%rdg±6dgt  ±3%rdg±10dgt ±3%rdg±4dgt ±3%rdg±25mΩ ±3%rdg±4dgt
Nominal test current at 0Ω external
loop: Magnitude/ Duration at 230V 		 L-N:6A/60ms
N-PE:10mA		 L-PE:15mA 20Ω:
  6A/20ms
200Ω:
  0.5A/20ms
2000Ω:
  15mA/500ms		 25A/20ms 6A/20ms
PSC/PFC
Range  2000A/20kA
(L-N(PSC)/L-PE(PFC))		 2000A/20kA
(PFC)		 2000A/20kA
(PFC)		 2000A/50kA
(PFC)		 2000A/20kA
(PSC)
Accuracy PSC/PFC accuracy is derived from measured loop impedance specification and measured voltage specification
RCD
Rated voltage 100-260V(50/60Hz)
Function x1/2, x1,x5,Ramp,Auto,Uc
6/10/30/100/300/500/1000mA/variable
RCD type AC(G/S) A(G/S) F(G/S) B(G/S) EV
Trip current setting


 		 x1/2,
x1,Uc		 10/30/100/300/
500/1000mA(G)
10/30/100/
300/500(S)		 10/30/100/
300/500mA		 10/30/100/
300/500mA		 10/30/100/
300mA		 6mA
(x1 only)
x5 10/30/100mA 10/30/100mA 10/30/100mA 10/30mA -
Ramp 10/30/100/
300/500mA		 10/30/100/
300/500mA		 10/30/100/
300/500mA		 10/30/100/
300mA		 6mA
Accuracy Trip
current		 x1/2 -8 - -2% -10 - 0% -10 - 0% -10 - 0% -
x1 +2 - +8% 0 - +10% 0 - +10% 0 - +10% 0 - +10%
x5 +2 - +8% 0 - +10% 0 - +10% 0 - +10% -
Ramp -4 - +4% -10 - +10% -10 - +10% -10 - +10% -10 - +10%
Trip
time		 x1/2 2000ms(G/S):±1%rdg±2ms -
x1 550ms(G):±1%rdg±2ms,1000ms(S):±1%rdg±2ms 10.5s:±1%±2㎳
x5 410ms(G/S):±1%rdg±2ms -
Continuity
Range  20.00/200.0/2000Ω (Auto-ranging)
Open circuit voltage(DC) 7-14V
Measuring
current		 200mA 200mA or more(2Ω or less)
15mA 15mA±3mA(short-circuit)
Accuracy  ±2%rdg±8dgt
Volts
Range  300.0/600V(Auto-ranging)
Measuring
ranges		 Volts 2-600V
Frequency 45-65Hz
Accuracy Volts ±2%rdg±4dgt
Frequency ±0.5%rdg±2dgt
Phase Rotation
Rated voltage 48-600V(45-65Hz)
Remarks Remarks Correct phase sequence: are displayed “1.2.3” and mark
Reversed phase sequence: are displayed “3.2.1” and mark
Earth
Range  20.00/200.0/2000Ω(Au to-ranging)
Accuracy ±2%rdg±0.08Ω(20.00Ω)
±2%rdg±3dgt(200.0/2000Ω)
General
Applicable standards IEC 61010-1 CAT IV 300V / CAT III 600 V Pollution degree 2
IEC 61010-2-034, IEC 61557-1,2,3,4,5,6,7,10
IEC 60529(IP40), IEC 61326(EMC)
Power source LR6 (AA) (1.5V) ×8
Communication interface USB
Dimension / Weight 136(L) × 235(W) × 114(D) mm / 1350g (including batteries)
Accessories Mains test lead※1
7281 (Test leads with remote control switch)
7246 (Distribution board test lead)
7228A (Earth resistance test leads)
8041 (Auxiliary earth spikes[2 spikes/1 set])
9084 (Soft case)
9142 (Carrying case)
9151 (Shoulder strap)
9199 (Shoulder pad)
8212-USB (USB adapter)
LR6(AA) × 8
Instruction manual
Calibration certificate
Optional Accessories 8259 (Adapter for measurement terminal)
7272 (Precision measurement cord set)
8017A (Extension prod long)
8602 (EVSE ADAPETER)
