Name: Hioki DT4252 DIGITAL MULTIMETER
Brand: Hioki
Availability: InStock

Shop	:	Tools Bangladesh 1
Product ID	:	303
Brand	:	Hioki
Availability	:	In Stock
Price BDT	:	0.00 Taka
Reviews	:
Share	:

Add To Cart

Customer Support
+8801965656380
Cash One Delivery
Pay after getting the product on hand
Warranty
1 Year warranty by manufacturer
Secured Payment Method
Your cart is always secure to shop
Easy Return Policy
7 days return without physical defect.

The Hioki DT4200 Digital Multimeter Series consist of a resolute idea lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super immediate nod rate and safety features that comply to electrical scrutiny to a sophisticated level.

The DT4252 is a digital multimeter expected specifically for general intend psychoanalysis, taking into account 0.3% DC V exactness, tackle current input and broad 40 Hz to 1kHz bandwidth.

Key Features: Hioki DT4252 DIGITAL MULTIMETER

±0.3% DC V basic accuracy, wide 40 Hz to 1 kHz AC V frequency characteristics
Measure up to 10A with direct input
Dual display lets you check voltage and frequency simultaneously
Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
USB communications function supports PC measurements (optional)

Specifications: Hioki DT4252 DIGITAL MULTIMETER

DC Voltage range	600.0 mV to 1000 V, 5 ranges Basic accuracy: ±0.3 % rdg. ±5 dgt.
AC Voltage range	6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz - 1 kHz Basic accuracy 40 - 500 Hz : ±0.9 % rdg. ±3 dgt. (True RMS, crest factor 3)
AUTO AC/DCV	N/A
Resistance range	600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.7 % rdg. ±5 dgt.
DC Current range	6.000 A / 10.00 A, 2 ranges, Basic accuracy: ±0.9 % rdg. ±5 dgt.
AC Current range	6.000 A / 10.00 A, 2 ranges, Basic accuracy 40 - 500 Hz : ±1.4 % rdg. ±3 dgt. (True RMS, crest factor 3, 40 Hz to 1 kHz)
AC Current range (use with Clamp on probes)	N/A
Voltage detection (50/60 Hz)	N/A
Capacitance range	1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9 % rdg. ±5 dgt.
Frequency range	AC V, AC A measurement: 99.99 Hz (5 Hz or more) to 9.999 kHz, 3 ranges, 99.99 kHz (only for AC V) Basic accuracy: ±0.1 % rdg. ±1 dgt.
Continuity check	Continuity threshold [ON]: 25 Ω or less (Indicate buzzer sound, red LED), [OFF]: 245 Ω or more Response time: 0.5 ms or more
Diode test	Open terminal voltage: 5.0 V or less, Testing current 0.5 mA or less, Threshold of forward voltage: 0.15 V to 1.5 V
Other functions	Filter function, Display value hold, Auto hold, Max/Min/Average value display, Relative display, Auto-power save, USB communication (option)
Display	Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph
Display refresh rates	5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s, Temperature: 1 time/s )
Power supply	LR03 alkaline batteries ×4, Continuous use: 130 hours (back light OFF)
Dimensions and mass	84 mm (3.31 in)W × 174 mm (6.85 in)H× 52 mm (2.05 in)D, 390 g (13.8 oz) (with batteries and holster)
