Includes: Fluke Ti480 PRO Infrared Camera
- Thermal imager with standard infrared lens
- AC power supply and battery pack charger (including universal AC adapters)
- Two, rugged lithium ion smart battery packs
- USB cable
- HDMI video cable
- 4 GB micro SD card
- Rugged, hard carrying case
- Soft transport bag
- Adjustable hand strap
- Available by free download Fluke Connect® SmartView® desktop software and users manual
Accessories: Fluke Ti480 PRO Infrared Camera
- IR lenses (4)
- Wide Angle Infrared Smart Lens
- 25* Micron Macro Infrared Smart Lens
- Smart Infrared 4x Telephoto Lens
- 2x Telephoto Infrared Smart Lens
- Chargers (1)
- Fluke Infrared Camera Car Charger
- Batteries (2)
- Fluke SBC3B Charging Base
- Fluke SBP3 Extra Battery Pack
- Other (3)
- Fluke Ti Visor 3
- Fluke Tripod Mounting Base
- Fluke Tripod Mounting Accessory 3
- Thermal imaging (1)
- Fluke Ti Eyepiece
Model: Fluke Ti480 PRO Infrared Camera
The Fluke Ti480 PRO Infrared Camera is working for Increased sensitivity to visualize temperature differences. Also, it has more performance and you can easily use it that because it's reliable trusted and very powerful.
With the Ti480 PRO MultiSharp focus captures images that are focused throughout the ground of view, though you begin from a totally blurry intend. The camera takes cumulative images and combines them to meet the expense of a sure, accurate yet to be the order of targets near and in the push away. See more detail since SuperResolution, offering 4x the pixel data. Using the software and SuperResolution you can view images serve on occurring to 1280 x 960 unlimited.
Save epoch taking into consideration the Fluke Connect system You can wirelessly sync images directly from your camera to the Fluke Connect system, and adding going on happening it to an asset scrapbook or encounter order. Having access to share records simultaneously at the inspection site and from the office or an off-site location enables faster decision making and real times collaboration along together in the midst of team members. You can in addition to alive stream the camera display to your smartphone or PC and remotely come happening once the child support for advice the camera. We Tool Bangladesh distributes brand new products so you can buy this Fluke Ti480 PRO Infrared Camera with its high-resolution camera.
Key features: Fluke Ti480 PRO Infrared Camera
- Increased sensitivity to visualize temperature differences
- Easier to visualize and diagnose issues with sharper onscreen images, multiple rectangle markers and 9 color palettes
- More intuitive visual interface, improved, user-tested, touch screen interface
- More flexibility to visualize target, tiny-to-large with interchangeable smart lenses - no calibration required, 2x and 4x telephoto, wide angle and macro lens compatibility
- Capture a clear, accurate image focused throughout the field of view with MultiSharp™ Focus
- Get an instant in-focus image of your designated target. LaserSharp® Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target.
- Get 4x the pixel data with SuperResolution, which captures multiple images and combines them to create a 1280 x 960 image
- Save time - wirelessly sync images directly from your camera to the Fluke Connect® system, and attach to an asset record or work order
- Reduce the need take notes in the field with IR-PhotoNotes™ and voice annotations
Specifications: Fluke Ti480 PRO Infrared Camera
Key features |
IFOV with standard lens (spatial resolution) |
0.93 mRad, D:S 1065:1 |
Detector resolution |
640 x 480 |
SuperResolution |
Captures and combines 4x the data to create a 1280 x 960 (614,400 pixels) image |
Infrared Resolution |
307,200 pixels |
MultiSharp™ Focus |
Yes, focused near and far, throughout the field of view |
LaserSharp® Auto Focus |
Yes, for consistently in-focus images |
Laser distance meter |
Yes, calculates distance to the target for precisely focused images and displays distance on screen |
Advanced manual focus |
Yes |
Ruggedized touchscreen display |
3.5 inch (landscape) 640 x 480 LCD |
Rugged, ergonomic design for one-handed use |
Yes |
Digital zoom |
2x and 4x |
Temperature measurement |
Temperature measurement range (not calibrated below -10 °C) |
≤-10 °C to 1000 °C (14 °F to 1832 °F) |
Accuracy |
±2 °C or 2% (at 25 °C nominal, whichever is greater) |
Thermal sensitivity (NETD)* |
≤0.05 °C at 30 °C target temp (50 mK) |
On-screen emissivity correction |
Yes (both value and table) |
On-screen reflected background temperature compensation |
Yes |
On-screen transmission correction |
Yes |
*Best possible |
Wireless connectivity |
To PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available) |
Fluke Connect® app compatible |
Yes*, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing |
Fluke Connect® Assets optional software |
Yes*, assign images to assets and create work orders. Easily compare measurement types in one location |
Fluke Connect® Instant Upload |
Yes*, connect your camera to your building’s WiFi network, and images taken automatically upload to the Fluke Connect system for viewing on your smartphone or PC |
Fluke Connect® tool compatible |
Yes*, connects wirelessly to select Fluke Connect enabled tools and displays measurements on camera screen |
IR-Fusion® technology |
Adds the context of the visible details to your infrared image |
AutoBlend™ mode |
Min, Mid, Max IR plus full visible on camera; continously variable in software |
Picture-In-Picture (PIP) |
Yes |
Built-in digital camera (visible light) |
5 MP |
Lenses |
Standard lens |
IFOV (spatial resolution) |
0.93 mRad, D:S 1065:1 |
Field of view |
34 °H x 24 °V |
Minimum focus distance |
15 cm (approx. 6 in) |
IR-Fusion® technology |
Picture-In-Picture and full screen |
Optional 2x telephoto smart lens |
IFOV (spatial resolution) |
0.65 mRad, D:S 1529:1 |
Field of view |
12 °H x 9 °V |
Minimum focus distance |
45 cm (approx. 18 in) |
IR-Fusion® technology |
Picture-In-Picture and full screen |
Optional 4x telephoto smart lens |
IFOV (spatial resolution) |
0.33 mRad, D:S 2941:1 |
Field of view |
6 °H x 4.5 °V |
Minimum focus distance |
45 cm (approx. 18 in) |
IR-Fusion® technology |
Picture-In-Picture and full screen |
Optional wide-angle smart lens |
IFOV |
2.62 mRad, D:S 377:1 |
Field of view |
46 °H x 34 °V |
Minimum focus distance |
15 cm (approx. 6 in) |
IR-Fusion® technology |
Full screen |
Level and span |
Smooth auto and manual scaling |
Fast auto toggle between manual and auto modes |
Yes |
Fast auto-rescale in manual mode |
Yes |
Minimum span (in manual mode) |
2.0 °C (3.6 °F) |
Minimum span (in auto mode) |
3.0 °C (5.4 °F) |
Data storage and image capture |
Extensive memory options |
Removable 4 GB micro SD memory card, 4 GB internal flash memory, save to USB flash drive capability, upload to Fluke Cloud™ for permanent storage |
Image capture, review, save mechanism |
One-handed image capture,review, and save capability |
Image file formats |
Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2); no analysis software required for non-radiometric (.bmp, .jpg and .avi) files |
