ProSim SPOT Light Patient Simulator Features

• Compact and portable design for easy transport and use

• Realistic vital signs simulation including ECG, SpO₂, respiration, and temperature

• User-friendly touchscreen interface for quick and intuitive control

• Wireless connectivity for remote operation and flexibility

• Pre-programmed clinical scenarios to enhance training effectiveness

• Supports multiple patient profiles for diverse simulation needs

• Adjustable heart rate, rhythm, and oxygen saturation parameters

• Simulates arrhythmias and abnormal rhythms for advanced cardiac training

• Battery-powered for use in various clinical environments without power dependency

• Compatible with standard patient monitoring equipment

• Lightweight and robust build for durability during training sessions

• Ideal for training medical professionals in emergency response, critical care, and patient monitoring

Technical Specifications:

• Simulation Capabilities:

  • ECG Waveforms: 12-lead ECG simulation with adjustable heart rate (20–300 bpm)

  • Pulse: Synchronized pulse output with adjustable pulse rate (20–300 bpm)

  • SpO₂: Simulates oxygen saturation levels (0–100%) and plethysmograph waveform

  • Respiration: Variable respiration rate simulation (5–60 breaths per minute)

  • Blood Pressure: Simulated non-invasive blood pressure (NIBP) with systolic/diastolic/mean pressures

  • Temperature: Simulated body temperature range (30–43 °C / 86–109 °F)

• Display:

  • High-resolution color touchscreen display for easy control and monitoring

  • Real-time waveform and vital sign display

• Connectivity:

  • Bluetooth and USB interfaces for wireless and wired control

  • Compatible with proprietary control software and mobile apps

• Power:

  • Rechargeable lithium-ion battery with up to 8 hours of continuous use

  • AC power adapter included for extended sessions

• Physical Dimensions:

  • Size: Approx. 12 cm x 10 cm x 3 cm (4.7 in x 3.9 in x 1.2 in)

  • Weight: Approx. 350 grams (0.77 lbs)

• User Interface:

  • Intuitive touchscreen menu with pre-set scenarios and customizable parameters

  • Manual override options for real-time parameter adjustment

• Safety and Compliance:

  • Complies with international medical device safety standards (ISO 13485, IEC 60601)

  • Non-invasive simulation with no patient risk

• Included Accessories:

  • ECG lead set

  • SpO₂ sensor

  • USB charging cable

  • Carrying case

• Applications:

  • Medical and nursing education

  • Advanced cardiac life support (ACLS) training

  • Clinical skills and emergency response simulation
