DX-Series FLIR Elara
The FLIR Elara DX-Series multispectral pan/direction/zoom (PTZ) security camera provides full situational watchfulness in the most punishing environments. Combining thermal and visible lively imagers, the Elara DX-Series gives operators the ability to monitor large areas in get your hands on dark, glare-free, and adverse weather. The exceptional detection and identification capabilities of multispectral cameras are being placed as soon as the money for solutions for challenging imaging problems at valuable infrastructure sites and remote facilities.
Key Features: DX-Series FLIR Elara
- MULTISPECTRAL IMAGING IN ANY CONDITION
Integrated thermal and visible sensors capture sharp video where other PTZ cameras cannot.
- DESIGNED TO WITHSTAND EXTREME ENVIRONMENTS
Built to handle the challenges of critical infrastructure sites and other demanding locations.
- SUPERIOR MONITORING OF LARGE AREAS AND CHANGING ENVIRONMENTS
PTZ capability gives operators continuous visibility in large areas plus optional thermal zoom up to 5x with 15 mm to 75 mm zoom lens
Specifications: DX-Series FLIR Elara
Environmental
Humidity
0-95% relative
IP Rating (dust & water ingress)
IP66
Operating Temperature Range
-40°C to 60°C
Shock
IEC 60068-2-27
Storage Temperature
-55°C to 85°C
Vibe
IEC 60068-2-64
General
Detector Type
Long-Life, Uncooled VOx Microbolometer
Focus Range
Athermalized, Focus-Free
Input Voltage
IEEE 802.3bt Type 3 (PoE++)
Universal PoE injector
Thermal Spectral Range
7.5 μm to 13.5 μm
Zoom
Visible: Optical Zoom: 31
Measurement & Analysis
Programmable Presets
256
PTZ
Tilt Speed
-10° to 190°
0.1° to 60°/sec
System Integration
Ethernet
10/100/1000 Mbps
Streaming Resolution
Thermal: QVGA to VGA
Visible: VGA to 4k
Supported Protocols
IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Thermal Camera
Optical Characteristics
FOV: 6° × 5°
Focal Length: 36 mm
Thermal Frame Rate
NTSC: 30 Hz or PAL: 25 Hz / 8.3 Hz
Thermal Image Settings
Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Visible Camera
Array format
320 × 240
Focal Length
6.5mm - 202mm
Lens Field of View
Visible:
HFOV: 61.8° - 2.15°
VFOV: 36.65° - 1.2°
Sensitivity
Visible:
Color: 0.25 Lux (@ (f1.6 AGC On, 30FPS)
B/W: 0.10 Lux (@ (f1.6 AGC On, 30FPS)
Video & Recording
Video Compression
Thermal: One channel of H.264 & M-JPEG
Visible: Two independent channels of H.264 & M-JPEG
Video Image Uniformity Optimization
Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
