Amprobe ACD-16 TRMS-PRO 1000A Clamp Meter is AC/DC voltage up to 600V, AC current up to 1000A, resistance, frequency, and temperature and it's rugged and reliable.
Need the precise tool to troubleshoot a system? Amprobe ACD-16 TRMS PRO provides a full range of measurements, enhanced when data logging capabilities, to catch what the eye cant sky. Double the efficiency, taking into consideration an optional PC interface kit.
Iconic Engineering offers it almost free delivery with the best price in Bangladesh.
Key Features: Amprobe ACD-16 TRMS-PRO 1000A Clamp Meter
- True-RMS and backlight screen
- Measurements: AC/DC voltage up to 600V, AC current up to 1000A, resistance, frequency, and temperature
- Data-logging 5400 points
- Optional PC interface capability (RS-232 KIT2)
- Audible continuity
- Auto power off
- Automatic polarity
- Low battery indication
- Data hold
- Large, easy to read LCD display
- Accommodates conductors up to 1.77 (45mm) in diameter
- Carrying case, thermocouple, test leads, batteries (installed) and user manual included
- Voltage overload protection for all functions up to 600V AC/DC
Specifications: Amprobe ACD-16 TRMS-PRO 1000A Clamp Meter
| FEATURE |
ACD-16 TRMS-PRO |
| True-rms |
• |
| AC Voltage |
600.0 V |
| DC Voltage |
600.0 V |
| AC Current |
40.0 A, 400.0 A, 1000 A |
| Resistance |
999.9 O |
| Frequency |
6.00 hz → 600.0 Hz |
| Temperature |
-58 °F → 572 °F (-50 °C → 300 °C) |
| Accommodates conductors |
up to 1.77 (45 mm) in diameter |
For complete specs please download the product datasheet under the “Resources” tab.
Includes: Amprobe ACD-16 TRMS-PRO 1000A Clamp Meter
- TRMS & Backlight Screen
- Measurements: AC/DC Voltage up to 600V, AC Current up to 1000A, Resistance, Frequency and Temperature
- Data-logging 5400 points
- Optional PC interface capability (RS-232 KIT2)
Accessories: Amprobe ACD-16 TRMS-PRO 1000A Clamp Meter.
- Carrying case,
- Thermocouple,
- Tests,
- Batteries (installed),
- Users manual
