Key Features: Quasar Premium Mini-Dome AI Quad HD 5 MP

• Artificial intelligence video analytics, on the edge

  Features advanced video analytics to help you detect with reliability, reduce false alarms, and quickly respond to threats.

• Advanced situational awareness

  Improves situational awareness by offering more lens options, advanced low-light/no-light features and an advanced multi-shutter WDR feature.

• Reliable and NDAA compliant

  With a 4-year warranty, IK10 and IP66 rating, and NDAA compliance, this camera extends product life, minimizes corrective maintenance, and optimizes the total cost of ownership.

Specifications: Quasar Premium Mini-Dome AI Quad HD 5 MP

General

Angle of View

102.1° × 70.2°

Automatic Electronic Shutter [AES]

1/1 to 1/32,000

Compression

Enhanced H.265 Main Profle + Enhanced H.264 Main/High/Baseline Profle + MJPEG"

Day/Night Mode

Yes

Digital Slow Shutter [DSS]

1/1 (1) - 1/60 (50) NTSC (PAL)

Dimensions

161 mm × 128.6 mm (6.3 in × 5 in)

Enclosure

Indoor/Outdoor: IK10 rated vandal IP66 NEMA 4X

Firmware Upgrade

Flash memory for upgrade of camera firmware over the network

Input Voltage

PoE IEEE802.3af, class 0 AC 24 V, DC 12 V

Power Connection

RJ45 & AC/DC

Power Consumption

POE: 12.95W AC 24V: 13.2W; 24.20 VA DC 12V: 13.31W

Privacy Zones

Yes

Scanning Mode

Progressive

Shutter WDR

3 Shutter, 130 dB

Tamper Detection

Yes

Unit Weight

1.3 kg (2.86 lb)

Compliance & Certifications

International

CE marked, EN61000-6-3, EN 62368-1 & EN50130-4, CB 62368-1, LVD (CoC), RoHS, RCM, WEEE, ISTA-3A

MTBF [hrs]

457097.0

ONVIF Compliance

Profiles S, G, M & T

USA

FCC Part 15 (subpart B, class A)

Cyber Security

Security

Password protection, IP address filtering, TLS/HTTPS, IEEE 802.1X network access control, Digest authentication, Password policy Protect from multiple failure login

Environmental

Humidity

90% (non-condensing)

Operating Temperature

-30°C to 60°C (-22°F to 140°F) without heater IR LED 100% max 50°C, 25% max 55°C -55°C to 60°C (-67°F to 140°F) with heater Cold start -40°C to 60°C (-40°F to 140°F) with heater IR LED 100% max 50°C, 25% max 55°C

Storage Temperature

-20°C to 70°C (-4°F to 158°F)

Environmental

Shock & Vibration

IEC 60068-2-64: 2008

Measurement & Analysis

Analytics Features

Person/Face/Vehicle; Intrusion-Region/ Tripwire; Object Counting, Loitering, Stopped Vehicle; Abandoned Object; Object Removal; Wrong Direction; Camera Sabotage; People Counting

Analytics Management

Web-based configuration and management, masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control

Measurement & Analysis

Bump/Vibration

IEC 60068-2-27: 2008

PTZ

Pan_Tilt_Spin

356° /±80° / ±98°

Sensor & Optical

Automatic Gain Control [AGC]

Auto

System Integration

Bi-directional Audio

1 Audio Line Input, G.711/G.726/AAC/LPCM support + 1 Audio Line Output

Distance

Up to 40 m (131 ft)
Sunshield 28 m (91.8 ft)

Ethernet

10/100/1000, IEEE 802.3, auto sensing 1 x RJ45

Input

1 dry alarm contact 1 5 V 10 kΩ pull up

Network Protocol

IPV4/6, HTTP, HTTPS, UPnP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, SNMP, QoS, TLS, SMTP, FTP, DDNS, PPPoE, RTCP

Output

1 Relay Contact max. DC 5 V 130MA

Peak Emission Wavelength [nm]

850.0

Remote Configuration

Via web browser or supported video management software

Supported Web Browser

Firefox, Chrome, Edge, Safari

Video & Recording

Maximum Performance

H.264/H.265 30/25 fps @ 5M (NTSC/PAL) + 30/25 fps @ D1 or H.264/H.265 15/12 fps @ 5M + 1080p + D1 (NTSC/PAL) or H.264/H.265 60/50 fps @ 1080p + 30/25 fps @ 720p + D1 (NTSC/ PAL)

Rate Control

CBR, CVBR, LBR, MJPEG

Resolution Range

Scalable from QCIF to 5 MP

SD Card Recording1

microSD/microSDHC/microSDXC 8 GB to 1 TB (Class 10)

Video Motion Detection

Yes

Visible Camera

Backlight Compensation

On / Off

Bandwidth

Configurable between 64 Kbps and 20 Mbps

Image Sensor

1/2.7-in CMOS

Lens Type

Motorized lens 2.7 mm to 12 mm, F1.6-F2.9
H-FOV: 102.14° (Wide); 31.53° (Tele)
V-FOV: 70.28° (Wide); 22.71° (Tele)

Mechanical IR Cut Filter

Yes

Noise Reduction

3D/2D/Color

Sensitivity

0.04 (color)/ 0.008 (BW, 0 Lux with IR illuminator ON, measured at 30 IRE

Sensor Resolution

2688 × 1944

Signal to Noise Ratio

±55 dB

White Balance

Auto / ATW / Manual / One Push
