Model: Pasi WELL-CAMERA.3 Borehole camera
Well-Camera3 brings significant improvements and greater handling in the world of visual inspections in wells and pipes: all the camera electronics have been miniaturized and incorporated on the cable reel.
This means that to perform a visual inspection in the well you need only the cable reel with the head of Well-Camera3, a portable PC and a USB powerbank or an external 12V battery (to be connected to the cable reel to power the camera itself). The lighting system of the Well-Camera3 has been greatly implemented, achieving twice the illumination intensity of previous models. Also for Well-Camera3 it is possible to use the electronic encoder for the automatic recording of the depth.
Operating conditions of the camera head: max Pressure 35bar (350m water column), Temperature Range -10°C +50°C
Key Features: Pasi WELL-CAMERA.3 Borehole camera
- Cable reel with camera head and control electronics that includes a dedicated video grabber board
- USB 2.0 cable for connection to external PC (not included) for audio/video viewing and recording
- Management software PASI WellCamera Recorder (for the control of all the functions of the camera and the visualization/recording audio/video to laptop PC of the Customer)
- Power cable for external USB/USB-C Powerbank (powerbank not included, available as accessory)
- Power cable for external 12V battery (battery not included)
Specifications: Pasi WELL-CAMERA.3 Borehole camera
CAMERA HEAD
Diameter
40mm
Length
150mm
Sensor type
CCD 1/3” in colour
Resolution
700 lines
Minimum light intensity required
0.005 lux @ F 1.2
Lens
2.9mm fixed lens - wide angle 120°
Light type
16x high-intensity LED (max. 400 lumen)
Waterproof protection
IP68, water column of 350m (35 bar)
CABLE REEL WITH CONTROL UNIT
Power supply
Standard 5V @ 2A powerbank – External 12V battery
Digital output
Built-in USB 2.0 for recording directly to external PC, 640x480 recording resolution
Encoder unit of measure
Meters/Feet, User selectable
