Features: Lutron PMS 713 Moisture Meter

• Designed to check the moisture level of wood, concrete, and other non-wood material.
• 6% to 40% moisture range on wood.
• 0 to 100% relative moisture value for concrete and other non-wood material.
• All in one, meter build in the test pins.
• Data hold function to freeze the desired value on display.
• Microprocessor circuit ensures high accuracy and provides special functions and features.
• Operates from DC 1.5V (UM4/AAA) x 4 PCS batteries.
• Built in low battery indicator.
• With the pins protection cover.
• Durable, long-lasting components, enclosed in strong, compact ABS-plastic housing.

Specifications: Lutron PMS 713 Moisture Meter

• ApplicationsDesigned to check the moisture level of wood, concrete and other non-wood material
• Measuring Principal
• Used the 2 pins electrode to measure the conductive ability of the species, then converter to the reading of % "Moisture and Content".
• DisplayLCD size: 28mm x 19mm
• Material/Range
• Material 1: 0 to 100% relative moisture value for concrete and other non-wood material.
• Material 2: 6% to 40% moisture range on wood.
• 1%
• Accuracy ? (5% + 5d)
• @ 23 ?C ? 5 ?C
• @ Material 1: 13% to 100%
• @ Material 2: 6% to 40%
• CircuitCustom one-chip of microprocessor LSI circuit.
• Probe2 pins moisture electrode
• Data Hold
• Freeze the display reading
• Sampling Time
• 0.8 seconds
• Operating Temperature
• 0 to 50 ?C
• Operating Humidity
• Less than 80% R.H.
• Power Supply
• DC 1.5V Battery (UM4/AAA) x 4PCS
• Power Current
• DC 4 mA
• weight 180 g / 0.40 LB @ Battery is included
• Dimensions180x40x40mm (7.1"x1.6"1.6")
