Lutron ph 206 Ph meter

Key Features: Lutron ph-206 Ph meter

• Multi functions: PH, mV, Temp.
• Automatic/manual temp. compensation.
• Large size ( 18 mm) LCD display.
• Built in analog output terminal.
•  mV function for ion-selective, ORP

SPECIFICATIONS: Lutron ph-206 Ph meter

Display 18 mm ( 0.7" ) LCD, 3 1/2 digits.
Measurement PH, mV, Temp. ( optional probe ).
Range/ PH : 0 to 14 pH x 0.01 pH
Resolution Temperature : 0 to 100 ℃ x 0.1 ℃.
Accuracy PH : ± ( 0.01 pH + 1d )
TEMP. : ± 0.8 ℃
mV : ± (0.5 % + 1d)
Temp., mV - within 23± 5 ℃ PH : Main instrument only.
Input Impedance 10^12 ohms.
PH range Temp. Manual : 0 ℃ to 100℃ external knob, adjust temp. values showed on display.
Compensation Auto temp. compensation : with the optional temp. probe, 0 to 100 ℃.
Analog Output The analog output is 0.1 mV/per digit of the display both of PH, mV,
Temp. function.
Sampling Time Approx. 0.4 second.
Operating Temp. 0℃ to 50℃ ( 32℉ to 122℉ )
Operating Humidity Less than 80% RH.
Calibration Knob External PH 4 ( slope adj. ) & PH 7 (Cal. adj.).
Power Supply 006P DC 9V battery.
Power Consumption Approx. 2.7 mA.
Dimension 160 x 80 x 35 mm, (6.3 x 3.2 x 1.4 inch).
Weight 250 g/0.55 LB (including battery).
PH electrode ( optional ) Any connector PH Electrode with BNC connector.
Standard Accessories Instruction Manual..........1 PC.
Optional Accessories PH electrode, ATC Temp. probe,

• N/A

ACCESSORIES: Lutron ph-206 Ph meter

• PH ELECTRODE General purpose pH electrode with BNC conector.
• PE-03 Range : 1 to 13 pH ( typical 0 to 14 pH ).
• Expoxy body, Body size : 12 mm dia. x 160 mm.
• Cable length : 1 meter.
• PH ELECTRODE General purpose & high quality pH electrode with BNC conector.
• PE-11 Range : 1 to 13 pH ( typical 0 to 14 pH ).
• Expoxy body, Body size : 9.5 mm dia. x 120 mm.
• Cable length : 1 meter.
• SPEAR PH Electrode The " Spear Tip pH electrode " is perfect for those pH measurements in
• PH-06HD, PH-04HD applications where sample piercing is required. Meat, sausage and cheese are
• ideal applications. The electrode features a very durable glass measuring
• spear packaged in a rugged virtually unbreakable epoxy body.
• Range : 0 to 14 pH ( PE-04HD), Range : 1 to 13 pH ( PE-06HD)
• BUFFER SOLUTION, PH-07 PH 7.00 standard buffer solution.
• BUFFER SOLUTION, PH-04 PH 4.00 standard buffer solution.
• PROBE, TP-06 The optional temperature probe for PH-206.
• CARRYING CASE, CA-03 Vinyl soft case for PH-206.
• CARRYING CASE, CA-06 Hard carrying case for PH-206.
