Kyoritsu 4200 Clamp Tester is glowing of measuring earth resistance levels together after that 0.05 and 1500, without the use of press on spikes in multi-earthing systems. Featuring large jaws which are meant for clamping directly onto a targeted chemical analysis application, the Kyoritsu 4200 can be in AC current. True RMS leakage or phase currents can be measured from 0.1mA to 30.0A to decide indispensable sponsorship more or less the earthing network.
With a built-in filter produce consequences, the Kyoritsu 4200 is clever to eliminate electrical noise to concord accurate results. These results are in addition to practice to be stored directly vis--vis the instrument, subsequently a built-in memory for 100 readings. Other features unique to this earth resistance clamp meter put in a scare perform, data terminate and a backlit LCD screen.
Key Features: Kyoritsu 4200 Earth Clamp Testers
• The earth resistance from 0.05 to 1500Ω can be measured without the auxiliary earth spikes. (The Multiple Earthing System.)
• True RMS
Accurate true RMS readings of AC current including distorted waveform from 1mA to 30.0A
• Noise Check Function A function to detect current, which affects an earth resistance measurement and displays the "NOISE" mark on the LCD.
• Memory function Save and display up to 100 measurement data.
• Data hold function / Buzzer function / Backlight function
• Compliant with Safety Standards of IEC 61010-1: CAT IV 300V Pollution degree2
Specifications: Kyoritsu 4200 Earth Clamp Testers
Specification
| Earth resistance (Auto-ranging) |
20.00/200.0/1500Ω
±1.5%±0.05Ω(0.00 to 20.99Ω)*1
±2%±0.5Ω(16.0 to 99.9Ω)
±3%±2Ω(100.0 to 209.9Ω)
±5%±5Ω(160 to 399Ω)
±10%±10Ω(400 to 599Ω)
Values are displayed, but accuracy isn't guaranted(600 to 1580Ω) |
AC current (50/60Hz)
(Auto-ranging) |
100.0/1000mA/10.00/30.0A
±2%±0.7mA(0.0 to 104.9mA)
±2%(80mA to 31.5A) |
| Operating indication |
Earth resistance function :
Constant voltage injection
Current detection (Frequency : Approx.2400Hz)
Dual Integration
AC current function : Successive approximation |
| Over-range indication |
"OL"is displayed when input exceeds the upper limit of a measuring range |
| Response time |
Approx. 7 seconds (Earth resistance)
Approx. 2 seconds (AC current) |
| Sample rate |
Approx. 1 times per second |
| Current consumption |
Approx. 50mA (max.100mA) |
| Measurement time |
Approx.12 hours (when R6 is used)
Approx.24 hours (when LR6 is used) |
| Auto power off |
Turns power off about 10 minutes after the last button operation. |
| Conductor size |
Approx. Ø32mm |
| Applicable standards |
IEC 61010-1 CAT Ⅳ 300V Pollution degree2
IEC 61010-2-032, IEC 61326 (EMC) |
| Power source |
LR6/R6 (AA)(1.5V) x 4 |
| Dimension |
246(L)×120(W)×54(D)mm |
| Weight |
Approx. 780g (including batteries) |
| Accessories |
8304 (Resister for operation check)
9166 (Carrying case[Hard])
R6 x 4, Instruction manual |
| Accessories |
8304 (Resister for operation check)
9166 (Carrying case[Hard])
R6 x 4, Instruction manual |
| Accessories |
8304 (Resister for operation check)
9166 (Carrying case[Hard])
R6 x 4, Instruction manual |
