Key Features:

• The DJI FPV Goggles support and record in 720p/60fps. This high-quality HD view is paired with a latency of 28 ms, providing users with a clear view and faster performance.
• Videos recorded and saved on the microSD card can be replayed instantly through the DJI FPV Goggles. [7]
• Pilots can share camera views with other DJI FPV Goggles that are set to Audience mode, allowing viewers to see what the racers see.
• The DJI Digital FPV System can be used with analogue image transmission via a third-party receiver, allowing users to switch between AV and digital video transmissions.

Specifications:

DJI FPV Goggles

• Weight

• Approx. 420 g (headband and antennas included)

• Dimensions

• 202×126×110 mm (antennas included),
  184×122×110 mm (antennas excluded)

• Screen Size

• 2-inch × 2

• Screen Resolution (Single Screen)

• 1440 × 810

• Screen Renew Rate

• 120 Hz

• Communication Frequency

• 5.725-5.850 GHz

• Transmitter Power (EIRP)

• FCC: <30 dBm; CE: <14 dBm; SRRC: <19 dBm

• Live View Mode

• Low Latency Mode (720p/120fps)
  High-Quality Mode (720p/60fps)

• Video Format

• MP4 (Video format: H.264)

• Supported Video Play Format

• MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3)

• Operating Temperature

• 32° to 104° F (0° to 40° C)

• Power Input

• Dedicated DJI Goggles batteries

• FOV

• Adjustable from 30° to 54°. Adjustable image size from 50%-100%

• Interpupillary Distance Range

• 58 -70 mm

• Supported Storage Card

• microSD cards with storage capacities of up to 128GB.

DJI FPV Air Unit

• Weight

• Air Unit (Camera included): 45.8 g
  3.9 g (MMCX elbow antenna each)

• Dimensions

• Air Unit: 44×37.8×14.4 mm
  Camera: 27.4×21.1×20.1 mm
  Coaxial Cable: 100 mm

• Operating Frequency

• 5.725-5.850 GHz

• Transmitter Power (EIRP)

• FCC/SRRC/MIC: <30 dBm;
  CE: <14 dBm

• Min. Latency (end-to-end)

• Low Latency Mode (720p/120fps): <28 ms
  High-Quality Mode (720p/60fps): <40 ms

• Max. Transmission Distance

• FCC/SRRC: <4 km;
  CE: <0.7 km;
  MIC: <2.5km

• Video Format

• MP4 (Video format: H.264; Audio format: ACC-LC)

• I/O Interface

• USB-C, MMCX, 3-in-1 port, microSD card slot

• Supported Flight Control System

• The DJI FPV Air Unit is only compatible with flight controllers that support Betaflight

• Operating Temperature Range

• 32° to 104°F (0° to 40°C)

• Input Power

• 7.4-17.6 V, about 4-9 W

• Channels

• 8

• Channels info

• FCC
  Channel 1: 5660
  Channel 2: 5695
  Channel 3: 5735
  Channel 4: 5770
  Channel 5: 5805
  Channel 6: 5878
  Channel 7: 5914
  Channel 8: 5839

  CE/SRRC
  Channel 1: 5735
  Channel 2: 5770
  Channel 3: 5805
  Channel 8: 5839

  MIC
  Channel 1: 5660
  Channel 2: 5700
  Channel 8: 5745

DJI FPV Camera

• Sensor

• 1/3.2'' CMOS; Effective Pixels: 4 M

• Lens

• 2.1 mm, f/2.1

• Shutter

• Rolling shutter

• ISO

• 100-25600

• FOV

• 150°(D); 122°(H); 93°(V)

• Dimension

• 22.1×21.1×20.1 mm

• Weight

• 8.2 g

DJI FPV Remote Controller

• Weight

• 765 g

• Operation Frequency

• 5.725-5.850 GHz

• Max. Transmission Distance(Unobstructed, free of interference)

• FCC/SRRC: 4 km; CE: 0.7 km

• Transmitter Power (EIRP)

• FCC: <30 dBm; CE: <14dBm; SRRC:<19dBm

• Operation Current/Voltage

• 0.6 A @ 7.6 V

• Operation Temperature

• 0° to 40°C (32° to 104°F)

• Charging Temperature

• 5° to 40°C (41° to 104°F)

Remote Controller intelligent Battery (WM37-4920mAh-7.6V)

• Battery Type

• LiPo 2S

• Capacity

• 4920 mAh

• Voltage

• 7.6 V

• Energy

• 37.39 Wh

SUPPORTED SD CARDS

• SUPPORTED SD CARDS

• Micro SD™
  Supporting Micro SD with capacity up to 128 GB and R/W speed up to UHS-I Speed Grade 3

• Recommended microSD Cards

• 16G
  Sandisk Extreme
  32G
  Sandisk Extreme V30
  64G
  Sandisk Extreme V30
  128G
  Sandisk Extreme V30
