Hioki clamp meters are best in class handheld current and voltage meters for safely and proficiently measuring gift lines.
The CM3286 clamp more or less finishing meter can piece of legislation voltage, current, execution, power factor, phase angle, reactive power or frequency, as nimbly as detecting phase sequence in this area rouse lines at any desired mitigation of a single-phase circuit or three-phase circuit.
Key Features: Hioki CM3286 AC CLAMP POWER METER
- Display four parameters simultaneously
- A handheld power meter that measures from 5 W of power and 60 mA of current Measure power ranging from 5 W at a low current of 60 mA to 360 kW
- In addition to current, voltage, and power, measure simple integral power consumption and phase sequence
- Features and functions deliver fast and efficient testing
- Hold measured values to send them to a smartphone, quick and easy data recording (CM3286-01 only)
Specifications: Hioki CM3286 AC CLAMP POWER METER
| Measurement line | Single-phase, Three-phase (balanced with no distortion) |
|---|---|
| Measurement items | Voltage, Current, Voltage/ current peak, Active/ reactive/ apparent power, Power factor, Phase angle *1, Frequency, Simple Active Energy Consumption (Single-phase) [CM3286-01 only*2] Voltage/ current harmonic levels |
| AC voltage range | [Measurement range] 80.0 V to 600.0 V, Single range, Basic accuracy 45 - 66 Hz: ±0.7% rdg. ±3 dgt. (Frequency characteristics: 45 to 1 kHz, True RMS) |
| AC current range | [Measurement range] 0.060 A to 600.0 A, 3 range, Basic accuracy: ±1.3% rdg. ±3dgt. (Frequency characteristics: 45 to 1 kHz, True RMS) |
| Power range | [Single phase] 0.005 kW to 360.0 kW Basic accuracy: ±2.0% rdg. ±7 dgt. (50/ 60 Hz, Power factor=1) [Balanced three-phase 3-wire] 0.020 kW to 623.5 kW Basic accuracy: ±3.0% rdg. ±10 dgt. (50/ 60 Hz, Power factor=1) [Balanced three-phase 4-wire] 0.040 kW to 1080 kW Basic accuracy: ±2.0% rdg. ±3 dgt. (50/ 60 Hz, Power factor=1) |
| Harmonic levels (CM3286-01only *2) | Voltage/ current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio |
| Other functions | [Phase angle *1] lead -180.0° to lag 179.9°, [Power factor] -1.000 to 1.000 [Frequency] 45.0 Hz to 999.9 Hz, PEAK, Phase detection, Max / Min / Avg value display, Auto hold, electric meter comparison, unbalanced 3-phase power estimate display, etc. |
| Dustproof and waterproof | IP54 (EN60529) Grip, excluding lever Risk of electric shock from measured conductors increases when wet |
| Interface | Bluetooth® 4.0LE, display measured values on an iOS or Android device |
| Power supply | LR03 Alkaline battery ×2, Continuous use: 25 hr (Backlight OFF) |
| Core jaw dia. | φ 46 mm (1.81 in) |
| Dimensions and mass | 82 mm (3.23in) W × 241 mm (9.49in) H × 37 mm (1.46in) D, 450 g (15.9 oz) |
Includes: Hioki CM3286 AC CLAMP POWER METER
- Hioki CM3286 AC CLAMP POWER METER
Accessories: Hioki CM3286 AC CLAMP POWER METER
| Accessories | Connection cord L9257 ×1, LR03 Alkaline battery ×2, Carrying case C0203 ×1, Instruction manual ×1 [CM3286-01 only]Notice Regarding Equipment That Emits Radio Waves ×1 |
|---|
