Hioki insulation testers or megohmmeters feature all-in-one designs, including built-in rugged cases and test lead storage compartments. The IR4017-20 is a single-range, 500 V/1000 MΩ analog insulation resistance tester with efficient functions and features to help shorten work time associated with field insulation testing. Safety CAT III 600 V.
HIOKI ANALOG MΩ HiTESTER IR4017 Price in Bangladesh offers reliable and accurate insulation resistance testing for professionals. Known for its durable build and precise analog measurement, the IR4017 is ideal for electrical maintenance and troubleshooting. Find the best deals and genuine products with competitive pricing in Bangladesh. Get the HIOKI ANALOG MΩ HiTESTER IR4017 Price in Bangladesh now and ensure top-quality performance for your testing needs.
Key Features
- Single range testing voltage of 500 V
- Test insulation resistance up to 1000 MΩ
- Built tough to withstand a 1-meter drop onto a concrete floor
- Bright LED luminous scale
- Check for live circuits and battery status
- Integrated hard case for quick and easy storage without disconnecting the leads
Basic specifications
Accuracy guaranteed: 1 year
| Rated output voltage |
500 V DC |
| Effective maximum indicated value |
1000 MΩ |
| Accuracy 1st effective measuring range |
±2 % of scale length, 1 M to 500 MΩ |
| Lower limit resistance |
0.5 MΩ (measurement resistance value to maintain testing voltage) |
| Overload protection |
600 V AC (10 sec.) |
| AC voltage range |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy,
500 kΩ or more input resistance |
| Other functions |
Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
| Power supply |
LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) |
| Dimensions and mass |
159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) |
| Included accessories |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
| Included accessories |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
| Included accessories |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
