Specifications:

Mavic 2 Pro & Mavic 2 Zoom

Mavic 2 Pro Camera

Sensor1” CMOS
Effective Pixels: 20 million

LensFOV: about 77°
35 mm Format Equivalent: 28 mm
Aperture: f/2.8–f/11
Shooting Range: 1 m to ∞

ISO RangeVideo:
100-6400
Photo:
100-3200 (auto)
100-12800 (manual)

Shutter SpeedElectronic Shutter: 8–1/8000s

Still Image Size5472×3648

Still Photography ModesSingle shot
Burst shooting: 3/5 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s)

Video Resolution4K: 3840×2160 24/25/30p
2.7K: 2688x1512 24/25/30/48/50/60p
FHD: 1920×1080 24/25/30/48/50/60/120p

Max Video Bitrate100Mbps

Color ModeDlog-M (10bit), support HDR video (HLG 10bit)

Supported File SystemFAT32 (≤ 32 GB)
exFAT (> 32 GB)

Photo FormatJPEG / DNG (RAW)

Video FormatMP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)

Mavic 2 Zoom Camera

Sensor1/2.3" CMOS
Effective Pixels: 12 million

LensFOV: about 83° (24 mm); about 48° (48 mm）
35 mm Format Equivalent: 24-48 mm
Aperture: f/2.8 (24 mm)–f/3.8 (48 mm)
Shooting Range: 0.5 m to ∞

ISO RangeVideo:
100-3200
Photo:
100-1600 (auto)
100-3200 (manual)

Shutter SpeedElectronic Shutter: 8–1/8000s

Still Image Size4000×3000

Still Photography ModesSingle shot
Burst shooting: 3/5/7 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s)

Video Resolution4K: 3840×2160 24/25/30p
2.7K: 2688×1512 24/25/30/48/50/60p
FHD: 1920×1080 24/25/30/48/50/60/120p

Max Video Bitrate100Mbps

Color ModeD-Cinelike

Supported File SystemFAT32 (≤ 32 GB)
exFAT (> 32 GB)

Photo FormatJPEG / DNG (RAW)

Video FormatMP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)

Aircraft

Takeoff WeightMavic 2 Pro: 907 g
Mavic 2 Zoom: 905g

DimensionsFolded:
214×91×84 mm (length×width×height)
Unfolded:
322×242×84 mm (length×width×height)

Diagonal Distance354 mm

Max Ascent Speed5 m/s (S-mode)
4 m/s (P-mode)

Max Descent Speed3 m/s (S-mode)
3 m/s (P-mode)

Max Speed (near sea level, no wind)72 kph (S-mode)

Maximum Takeoff Altitude6000 m

Max Flight Time (no wind)31 minutes (at a consistent 25 kph)

Max Hovering Time (no wind)29 minutes

Max Flight Distance (no wind)18 km (at a consistent 50 kph)

Max Wind Speed Resistance29–38 kph

Max Pitch Angle35° (S-mode, with remote controller) 25° (P-mode)

Max Angular Velocity200°/s

Operating Temperature Range-10°C to 40°C

Operating Frequency2.400 - 2.483 GHz
5.725 - 5.850 GHz

Transmission Power (EIRP)2.400 - 2.483 GHz
FCC：≤26 dBm
CE：≤20 dBm
SRRC：≤20 dBm
MIC：≤20 dBm
5.725-5.850 GHz
FCC：≤26 dBm
CE：≤14 dBm
SRRC：≤26 dBm

GNSSGPS+GLONASS

Hovering Accuracy RangeVertical:
± 0.1 m (when vision positioning is active)
± 0.5 m (with GPS positioning)
Horizontal:
± 0.3 m (when vision positioning is active)
± 1.5 m (with GPS positioning)

Internal Storage8 GB

Gimbal

Mechanical RangeTilt: -135–45° Pan: -100–100°

Controllable RangeTilt: -90–30° Pan: -75–75°

Stabilization3-axis (tilt, roll, pan)

Max Control Speed (tilt)120° /s

Angular Vibration Range±0.01° (Mavic 2 Pro)
±0.005° (Mavic 2 Zoom)

Sensing System

Sensing SystemOmnidirectional Obstacle Sensing1

ForwardPrecision Measurement Range: 0.5 - 20 m
Detectable Range: 20 - 40 m
Effective Sensing Speed: ≤ 14m/s
FOV: Horizontal: 40°, Vertical: 70°

BackwardPrecision Measurement Range: 0.5 - 16 m
Detectable Range: 16 - 32 m
Effective Sensing Speed: ≤ 12m/s
FOV: Horizontal: 60°, Vertical: 77°

UpwardPrecision Measurement Range: 0.1 - 8 m

DownwardPrecision Measurement Range: 0.5 - 11 m
Detectable Range: 11 - 22 m

SidesPrecision Measurement Range: 0.5 - 10 m
Effective Sensing Speed: ≤ 8m/s
FOV: Horizontal: 80°, Vertical: 65°

Operating EnvironmentForward, Backward and Sides:
Surface with clear pattern and adequate lighting (lux > 15)
Upward:
Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)
Downward:
Surface with clear pattern and adequate lighting (lux > 15)
Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

Remote Controller

Operating Frequency2.400 - 2.483 GHz; 5.725 - 5.850 GHz

Max Transmission Distance (unobstructed, free of interference)2.400 - 2.483 GHz; 5.725 - 5.850 GHz
FCC: 10000 m
CE: 6000 m
SRRC: 6000 m
MIC: 6000 m

Operating Temperature Range0℃ - 40℃

Transmission Power (EIRP)2.400 - 2.483 GHz
FCC: ≤26 dBm
CE: ≤20 dBm
SRRC: ≤20 dBm
MIC: ≤20 dBm
5.725-5.850 GHz
FCC: ≤26 dBm
CE: ≤14 dBm
SRRC: ≤26 dBm

Battery3950 mAh

Operating Current/Voltage1800 mA ⎓ 3.83 V

Supported Mobile Device SizeMax length: 160 mm; max thickness: 6.5–8.5 mm

Supported USB Port TypesLightning, Micro USB (Type-B), USB-C

Charger

Input100-240 V, 50/60 Hz, 1.8A

OutputMain: 17.6 V ⎓ 3.41 A
or 17.0 V ⎓ 3.53 A USB: 5 V⎓2 A

Voltage17.6 ± 0.1 V

Rated Power60 W

Intelligent Flight Battery

Capacity3850 mAh

Voltage15.4 V

Max Charging Voltage17.6 V

Battery TypeLiPo 4S

Energy59.29 Wh

Net Weight297 g

Charging Temperature Range5℃ to 40℃

Max Charging Power80 W

APP

Video Transmission SystemOcuSync 2.0

NameDJI GO 4

Live View QualityRemote Controller:
720p@30fps / 1080p@30fps
DJI Goggles:
720p@30fps / 1080p@30fps DJI Goggles RE:
720p@30fps / 1080p@30fps

Latency (depending on environmental conditions and mobile device)120 - 130 ms

Max Live View Bitrate12Mbps

Supported SD Cards

Supported SD CardsMicro SD™
Supports a microSD with capacity of up to 128 GB. A UHS-I Speed Grade 3 rating microSD card is required.

Recommended microSD Cards32G
Sandisk V30
Sandisk Extreme V30 Pro
64G
Sandisk Extreme Pro V30
128G
Sandisk Extreme V30
Sandisk Extreme Pro V30
Kingston Canvas Go!
Kingston Canvas React

Footnotes

Footnotes[1] Omnidirectional Obstacle Sensing includes left/right, up/down, and forward/backward obstacle sensing. Sensing for left/right directions is only available in ActiveTrack , POI, QuickShot and Tripod mode. Omnidirectional Obstacle Sensing does not fully cover the circumference of a 360-degree arc. And left and right obstacle sensing system only works in specific modes and environments. DJI warranty does not cover any loss caused by crashing when flying left or right, even when ActiveTrack or Tripod mode is activated. Please be aware of your surroundings and App notifications when operating the Mavic 2 to ensure safety.

These specs have been determined through tests conducted with the latest firmware. Firmware updates can enhance performance, so updating to the latest firmware is highly recommended.

The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
