Specifications
General Specifications
AC Current 400mA, 4A, 30A
AC Current Basic Accuracy ±1.5%
AC Current Max Resolution 0.1mA
AC Voltage 400V
AC Voltage Basic Accuracy ±(2.0% of reading + 5 digits)
AC Voltage Max Resolution 0.1V
DC Current 4A, 40A
DC Current Max Resolution 0.001A
DC Voltage 400V
DC Voltage Basic Accuracy ±(1.0% of reading + 2 digits)
DC Voltage Max Resolution 0.1V
Jaw Size 0.9" (23mm), conductors up to 4/0 AWG
True RMS Yes
Additional Details
Certifications CE, UL
Dimensions 7 × 1.8 × 1.3" (178 × 45 × 32mm)
Display 4000-count segment LCD
Safety Category CAT III-300V
Warranty 2 years
Weight 8oz (225g)
