KYORITSU KEW 4105DLBT-H EARTH TESTER:
The KYORITSU KEW 4105DLBT-H is an advanced earth tester designed for precise ground resistance measurements. Featuring Bluetooth connectivity, it enables seamless data transfer and remote monitoring, improving workflow efficiency. With high accuracy and a user-friendly interface, this tester is ideal for ensuring grounding safety in various electrical installations, providing reliable measurements for both residential and industrial applications.
Are you looking for an Earth Tester? Tools Bangladesh is an exclusive supplier in Bangladesh. Yes, now you are in the right place and can get this rugged and reliable earth tester at the best price in Bangladesh.
Key Features:
- 3-Pole and 2-Pole Earth Resistance measurement (0.01-2000Ω)
- Waterproof design (IP67)
- Built-in Bluetooth® enables data transfer
- Noise rejection up to 25V rms allows accurate testing in noisy environments
- Rotary Switch makes the user interface very intuitive
- Large LCD Display with Backlight
- LED to monitor correct / non correct auxiliary earth spike resistance
- Earth Voltage Measurement (AC/DC 0-300V)
- CAT Ⅳ 100V
Specifications:
| Earth resistance measurement |
20Ω | 200Ω | 2000Ω | ||||
|---|---|---|---|---|---|---|---|
| Measuring range | 0.00 - 2000 Ω | ||||||
| Display range | 0.00 - 20.99 Ω | 0.0 - 209.9 Ω | 0 - 2099 Ω | ||||
| Accuracy*1 | ±1.5%rdg±0.08 Ω*2 | ±1.5%rdg±4dgt | |||||
| Auxiliary earth resistance*3 | <10kΩ | <50kΩ | <100kΩ | ||||
| Comparator reference value | 10Ω | 100Ω | 500Ω | ||||
| Earth voltage measurement | |||||||
| Measuring range | 0 - 300 V AC (45 - 65Hz) | ±0 - ±300 V DC | |||||
| Display range | 0.0 - 314.9 V | 0.0 - ±314.9 V | |||||
| Accuracy | ±1%rdg±4dgt | ||||||
| Applicable Standards | IEC 61010-1 CAT Ⅳ 100V / CAT Ⅲ 150V / CAT Ⅱ 300V Pollution degree 3 IEC 61010-2-030, IEC 61010-031, IEC 61557-1, 5 IEC 60529 (IP67), IEC 61326-1, 2-2 |
||||||
| Communication interface | Bluetooth®5.0 | ||||||
| Power source | LR6(AA)(1.5V) × 6 | ||||||
| Dimension | 121(L) × 188(W) × 59(D) mm (including case lid) | ||||||
| Weight | Approx. 690g (including batteries and case lid) | ||||||
| Accessories | 7127B (Simplified measurement probe) 7266 (Earth resistance test leads [red:20m, yellow:10m, green:5m/1set]) 8041 (Auxiliary earth spikes [2spikes/1set]) 9121 (Shoulder strap) 9197 (Hard case) LR6(AA) × 6, Instruction manual |
||||||
| Optional Accessories | 7267 (Cable reel for Earth resistance tester [red:20m]) 7268 (Cable reel for Earth resistance tester [yellow:10m]) 7271 (Earth resistance test lead [green:5m]) 7272 (Precision measurement cord set) 8259 (Adapter for measurement terminal) 9190 (Carrying case) 9192 (Carring case for cord reels) 7269 (Earth resistance test lead (Red 20m)) 7270 (Earth resistance test lead (Yellow 10m)) |
||||||
