Fluke 9062 Motor and Phase Rotation Indicator
The Fluke 9062 is a specialized handheld device built to solve two common problems on the job site in one go - checking three-phase sequence and confirming motor shaft rotation, without ever needing to touch a live conductor or a spinning shaft.
For electricians and technicians working with three-phase electrical systems, getting the phase sequence wrong before connecting a motor can lead to reversed rotation, equipment damage, or unsafe startup conditions. The 9062 eliminates the guesswork - simply connect the included test leads to the three phases, and the unit instantly shows you the rotation direction (clockwise or counter-clockwise) through clear LED indicators on its display.
What sets this device apart is its contactless motor rotation detection. Instead of relying on a visible shaft or manual observation, the Fluke 9062 uses non-contact sensors to detect rotation direction on both synchronous and asynchronous three-phase motors - even when the shaft itself is hidden or enclosed. This makes it especially useful for technicians working with sealed or mounted motors and industrial machinery where visual inspection isn't practical.
The unit ships with adjustable test probes designed to grip securely across a range of contact points, including standard and industrial-rated sockets - so you get a safe, stable connection every time, whether you're on a factory floor, in a control panel, or servicing commercial HVAC equipment.
Built for CAT III 300V environments, the Fluke 9062 is a compact, reliable addition to any electrical test and measurement toolkit, helping reduce installation errors, downtime, and rework on three-phase power projects.
Key Features
- Three-phase sequence detection - instantly identifies phase order on 3-phase power supplies
- Phase rotation indication - clearly shows clockwise or counter-clockwise rotation direction via LED display
- Motor shaft rotation indication - determines the rotation direction of synchronous and asynchronous 3-phase motors
- Contactless detection on running motors - checks rotation direction without touching the motor shaft, ideal for enclosed or hard-to-reach motors
Technical Specifications
| Specification |
Value |
| Voltage range |
Up to 400 V |
| Phase display |
120–400 V AC |
| Frequency range |
2–400 Hz |
| Operating timer |
Continuous |
Environmental Specifications
| Specification |
Value |
| Operating temperature |
0 °C to 40 °C |
| Operating altitude |
Up to 2000 m |
| Humidity (non-condensing) |
15% to 80% |
| Dust/water resistance |
IP 40 |
Safety Specifications
| Specification |
Value |
| Electrical safety standard |
EN 61010, EN 61557-7 |
| Overvoltage category |
CAT III, 300 V |
Mechanical & General Specifications
| Specification |
Value |
| Dimensions |
124 x 61 x 27 mm |
| Weight |
1 x 9 V |
| Battery |
1 x 9V |
| Warranty |
1 year |
