FLIR Elara™ R-290 Commercial Ground Radar
The FLIR Elara R-290 is a compact arena radar used to detect and pay for in front caution of intruders as part of a larger video surveillance system. Radars can track targets in all weather and lighting conditions and enthusiastically map them in definite become primeval-fashioned for slope penetration. The Elara R-290 features a 90-degree arena of view and going on to 400-meter range for vehicle tracking and 200-meter range for human tracking, providing broad-place sponsorship and situational watchfulness on severity of the fence heritage. With simultaneous tracking of taking place to 32 targets and geolocation facility, the Elara R-290 can activate alarms and lead PTZ cameras for visual assertion to maximize security coverage and accretion the amount of era suitable to react to a threat.
Key Features: FLIR Elara™ R-290 Commercial Ground Radar
- Detect intrusions faster
Receive advanced warning of intrusions beyond the fence line. Scan field of view up to 10 times per second for fast target detection and smooth tracking of humans and vehicles.
- Expand situational awareness
Continuously track and precisely locate up to 32 targets simultaneously, and quickly intercept threats in any environmental or weather condition.
- Integrate quickly and affordably
Integrate radar target tracking information with video management systems (VMS) for precise accuracy and full control.
Specifications: FLIR Elara™ R-290 Commercial Ground Radar
General
I/Os
RJ45 Ethernet, 10-pin Terminal Block
Input Voltage
12V DC, 24V AC, and POE+
RF Transmit Power
14dBm (0.025W)
Weight
5.1lbs (2.3kg)
Environmental
IP Rating
IP66
Operating Temperature
-40°C to 70°C
Environmental & Certifications
Non-Operating Temperature
-50°C to 85°C
General
Box Contents
Radar, Back Box, Back Box Cover, Back Box Side Cover, Wall Mount Plate, RJ45 Cover, Screw Driver, Hex Wrench, 10-Pin I/O Connector
Dimensions (H x W x D)
6.3in × 6.3in × 7.7in (161mm × 161mm × 195mm)
Measurement & Analysis
Angular Accuracy
0.6m
Coverage Area
7.6 acres / 30,000m2 (Human Detection)
Frequency Range
24.075-24.175GHz
Human Detection Range
200m
Min Target Detection Speed
0.2m/s
Range Resolution
1.5m
Target Information
GPS coordinates, velocity, RCS, range, azimuth angle/direction, heading, course/track, target ID
Vehicle Detection Range
400m
Pan-Tilt
Tilt Range
+30° / -60°
Sensor & Optical
Field of View [H x V]
90 x 20
Refresh Rate
Up to 10Hz
