An oscilloscope is an electronic device that displays the change in voltage signal over time. It is mainly used to understand the relationship between time and voltage. A waveform image is displayed on the screen of the oscilloscope, which helps in analyzing the characteristics of the signal such as frequency, amplitude, waveform, etc. The use of oscilloscopes is widespread in engineering, physics, and electronics. It plays a special role in identifying faults in machines or circuits.
Current digital oscilloscopes capture the signal digitally, making more detailed analysis possible. An oscilloscope is an essential device to understand the shape and change of any electrical signal. Students and researchers use it to observe the results of various experiments in the laboratory. It is easy to find faults in the signal and verify the functionality of the device through the oscilloscope. Therefore, it is considered a very important tool in the scientific and technical fields.
