UNI-T UT572 Advanced Earth Resistance Tester:
The UNI-T UT572 Advanced Earth Resistance Tester is specifically designed for measuring earth resistance and soil resistivity. It features automatic interface connection checks and the ability to detect interference voltage and frequency, ensuring accurate measurements. With data hold and indication functions, this tester simplifies data reading and analysis. The UT572 can perform 2, 3, and 4-wire measurements, making it versatile for various on-site applications, including power equipment wiring and lightning protection systems. Its advanced capabilities make it an essential tool for professionals in electrical safety and maintenance.
Are you looking for an Earth Tester? Tools Bangladesh is an exclusive supplier in Bangladesh. Yes, now you are in the right place and can get this rugged and reliable earth tester at the best price in Bangladesh.
Key Features:
- Large 4-digit LCD Display, 5s sampling time
- 2/3/4-wire earth resistance and soil resistivity measurements
- Selectable test frequencies (94Hz/128Hz)
- Disturbance voltage (Ust) and frequency (Fst) measurement
- Earth resistance, RH and RS measurements
- LCD backlight; auto power off
- Data hold
- 20 sets of data storage
- Double insulation
- Compensating resistance RK measurement
Specifications:
|
Specifications
|
Range
|
UT572
|
|
Earth resistance (Re)
|
4Ω
|
±(3%+15)
|
|
40Ω
|
±(3%+5)
|
|
400Ω
|
|
4kΩ
|
|
40kΩ
|
|
Soil resistivity (ρ)
|
4Ω
|
ρ=2×π×L×Re (Depending on the test result
of Re)
|
|
40Ω
|
|
400Ω
|
|
4kΩ
|
|
40kΩ
|
|
Disturbance voltage (Ust)
|
50V (DC voltage/40Hz~500Hz)
|
±(3%+3)
|
|
Disturbance frequency (Fst)
|
40Hz~500Hz
|
±(1%+2)
|
|
Features
|
|
2/3/4-wire test
|
|
√
|
|
Earth resistance test frequency
|
94/128Hz
|
√
|
|
Soil resistivity test distances
|
1~40m
|
√
|
|
Earth resistance RH and RS test
|
|
√
|
|
Compensating resistance RK test
|
|
√
|
|
Data hold
|
|
√
|
|
Data storage
|
<
/td>
|
20
|
|
LCD backlight
|
|
√
|
|
Auto power off
|
Around 5 minutes
|
√
|
|
Low battery indication
|
≤9.5V
|
√
|
|
General Characteristics
|
|
Power
|
1.5V battery (LR6) x 8
|
|
Display
|
125mm x 37mm
|
|
Product color
|
Red and grey
|
|
Product net weight
|
1100g
|
|
Product size
|
210mm x 175mm x 90mm
|
|
Standard accessories
|
Batteries, simple test leads with alligator clips(double plugs x 1, single plug x 1), earth spike x 4, standard test leads with alligator clips (40m red x 1, 20m red x 1, 20m black x 1, 10m yellow x 1, 5m green x 1), gallus
|
|
Standard individual packing
|
Gift box, carrying bag, tool box, English manual
|
|
Standard quantity per carton
|
2pcs
|
|
Standard carton measurement
|
475mm x 378mm x 335mm (0.064CBM per standard carton)
|
|
Standard carton gross weight
|
14kg
|
