UNI-T UT278B & C & D Series Ground pile clamp earth resistance tester:
The UNI-T UT278B, UT278C, and UT278D Series Ground Pile Clamp Earth Resistance Testers are specialized instruments designed for measuring earth resistance in grounding systems. These testers feature a robust clamp design that allows for non-invasive measurements, making them ideal for testing ground resistance without the need for disconnection.
UT278B/C/D Series grounding clamp meters are used for the grounding resistance test. With clamp measurement, 3-wire or 4-wire measurement, voltage/current measurement, data storage/view, alarm, automatic shutdown, and other functions.
Models: UT278B, UT278C, UT278D
Are you looking for an Earth Tester? Tools Bangladesh is an exclusive supplier in Bangladesh. Yes, now you are in the right place and can get this rugged and reliable earth tester at the best price in Bangladesh.
Key Features:
- 2.4-inch color LCD
- Earth resistance measurement
- Leakage current measurement
- Load current measurement
- Grounding voltage measurement
- Soil resistivity measurement (UT278C & D)
- Alarm function
- USB data transfer
- Built-in rechargeable lithium battery
Specifications:
| Specifications |
|
| Function |
Range (UT278B) |
Range (UT278C) |
Range (UT278D) |
| Ground Resistance |
0.00Ω–1500Ω |
0.00Ω–1800Ω |
0.00Ω–2000Ω |
| Current (AC) |
0.000A–40A |
0.000A–50A |
0.000A–60A |
| Current resolution |
1uA |
1uA |
1uA |
| 3 or 4-wire method resistance |
0.00Ω–3KΩ |
0.00Ω–30KΩ |
0.00Ω–30KΩ |
| Soil Resistivity |
N/A |
0.00Ω–9999KΩ |
0.00Ω–9999KΩ |
| Ground voltage |
600V |
600V |
600V |
Accuracy Guaranteed
Temperature Humidity |
23℃±5℃，below 75%rh |
23℃±5℃，below 75%rh |
23℃±5℃，below 75%rh |
| Features |
|
| Power supply |
1, DC 3.7V lithium battery;
2, Real-time display of battery power, reminding to charge in time
|
| Jaw size |
68mm |
| Screen |
2.4 inch (46*29mm) color LCD |
| Measurement time |
1 time/sec |
| USB data upload |
The stored data can be uploaded, saved and printed. |
| Data storage |
500 set |
| Overload |
Overload indication “OL” |
| Backlight |
√ |
| Alarm function |
√ |
| Auto power off |
Around 15 minutes |
| Power consumption |
750mA MAX |
| Overload protection |
√ |
| Weight |
975g (including battery) |
| Operating temperature |
-10℃ — 50℃; below 80%RH |
| Storage temperature |
-10℃ — 60℃; below 70%RH |
| Insulation resistance |
>20MΩ (500V between circuit and case) |
| Withstand voltage |
AC 3700V/RMS (between circuit and case) |
| External magnetic field |
＜40A/m |
| External electric field |
＜1V/m |
| Applicable safety regulations |
IEC61010-1; IEC61010-031; IEC61557-1(Ground resistance);
CAT Ⅲ 300V, CAT IV 150V; Pollution degree: 2 |
