KYORITSU KEW 4202 EARTH CLAMP TESTER:
The KYORITSU KEW 4202 is an advanced earth clamp tester designed for measuring ground resistance without the need for disconnection. This portable and easy-to-use device features a clamp design that allows for quick and efficient measurements of earth grounding systems. With high accuracy and a clear display, the KEW 4202 is ideal for professionals in electrical maintenance and safety testing. It provides essential data for ensuring the effectiveness of grounding systems, making it a reliable tool for both residential and industrial applications.
Are you looking for an Earth Tester? Tools Bangladesh is an exclusive supplier in Bangladesh. Yes, now you are in the right place and can get this rugged and reliable earth tester at the best price in Bangladesh.
key Features:
- The earth resistance from 0.05 to 1500Ω can be measured without the auxiliary earth spikes in multi-earthing systems
- True RMS leakage or phase current readings from 0.1mA to 30.0A provide vital additional information in earthing networks
- Filter function offers increased immunity to electrical noise and a Noise mark appears in excessively high noisy environments
- Memory functions up to 100 data
- Bluetooth® communication
Specification:
| Earth resistance (Auto-ranging) |
20.00/200.00/1500Ω
±1.5%±0.05Ω(0.00 - 20.99Ω) *1
±2%±0.5Ω(16.0 - 99.9Ω)
±3%±2Ω(100.0 - 209.9Ω)
±5%±5Ω(160 - 399Ω)
±10%±10Ω(400 - 599Ω)
Values are displayed, but accuracy isn't guaranted(600 - 1580Ω) |
| AC current (50Hz/60Hz) (Auto-ranging) |
100.0/1000mA/10.00/30.0A
±2%±0.7mA(0.0 - 104.9mA)
±2%(80mA - 31.5A) |
| Operating indication |
Earth resistance function :
Constant voltage injection
Current detection (Frequency : Approx.2400Hz)
Dual Integration
AC current function : Successive approximation |
| Over-range indication |
"OL"is displayed when input exceeds the upper limit of a measuring range |
| Response time |
Approx. 7 seconds (Earth resistance)
Approx. 2 seconds (AC current) |
| Sample rate |
Approx. 1 times per second |
| Communication interface |
Bluetooth®5.0 |
| Current consumption |
Approx. 50mA (max.100mA) |
| Measurement time |
Approx.5 hours (when R6 is used)
Approx. 21 hours (when LR6 is used) |
| Auto power off |
Turns power off about 10 minutes after the last button operation. |
| Conductor size |
Approx.Ø32mm |
| Applicable standards |
IEC 61010-1 CAT Ⅳ 300V Pollution degree2
IEC 61010-2-032, IEC 61326 (EMC) |
| Power source |
LR6/R6(AA) (1.5V) x 4 |
| Dimension |
246(L)×120(W)×54(D)mm |
| Weight |
Approx. 780g (including batteries) |
| Accessories |
8304 (Resister for operation check)
9167 (Carrying case[Hard])
LR6 x 4, Instruction manual |
