KYORITSU KEW 4105A EARTH TESTER:
The KYORITSU KEW 4105A is a robust earth tester designed for accurate measurement of earth resistance. Featuring multiple measurement methods, including 2-pole and 4-pole testing, it ensures reliable results in various applications. The user-friendly interface and clear digital display facilitate easy operation, making it suitable for both experienced technicians and beginners. Compact and portable, the KEW 4105A is ideal for electrical safety inspections, grounding system evaluations, and compliance testing in residential, commercial, and industrial environments.
Are you looking for an Earth Tester? Tools Bangladesh is an exclusive supplier in Bangladesh. Yes, now you are in the right place and can get this rugged and reliable earth tester at the best price in Bangladesh.
Key Features:
- 3-Pole and 2-Pole Earth Resistance
- The latest circuit design permits the instrument to operate with the minimum of influence from earth voltage and earth resistance of auxiliary earth spikes
- Dust and drip proof (designed to IEC 60529 IP54)
- Earth resistance value can be read directly from the scale
- Designed to meet IEC 61010-1 safety standard
- Capable of measuring earth voltage
- Small and lightweight. Shock resistant new case material
- 2mA measuring current permits earth resistance tests without tripping earth leakage current breakers in the circuit under test
Specification:
Earth resistance
measurement |
20Ω |
200Ω |
2000Ω |
|
Measuring range |
0.00 - 1999Ω |
| Display range |
0.00 - 19.99Ω |
0.0 - 199.9Ω |
0 - 1999Ω |
| Accuracy |
±2%rdg±0.1 Ω |
±2%rdg±3dgt |
| Earth voltage measurement |
|
Measuring range |
0 - 200 V AC (50,60Hz) |
| Display range |
0.0 - 199.9 V |
| Accuracy |
±1%rdg±4dgt |
| Overload protection |
Earth resistance : 280V AC (10 seconds)
Earth voltage : 300V AC (1 minute) |
| Applicable standards |
IEC 61010-1 CAT Ⅲ300 V Pollution degree 2
IEC 61010-2-030, IEC 61557-1,5, IEC 60529 (IP54) |
| Power source |
R6(AA)(1.5V) × 6 |
| Dimension |
105(L) × 158(W) × 70(D) mm (including case lid) |
| Weight |
Approx. 550g (including batteries and case lid) |
| Accessories |
7095A (Earth resistance test leads (Red 20m, Yellow 10m, Green 5m/1set))
7127B (Simplified measurement probe)
8032 (Auxiliary earth spikes[2 spikes/1set])
9121 (shoulder strap)
9084 (Carrying case)
R6(AA) × 6, Instruction manual |
| Optional accessories |
7245A (Precision measurement cord set)
8259 (Adapter for measurement terminal)
9165 (Carring case [Hard]) |
