Hioki’s non-contact voltage detection and measurement technology places efficiency and safety as priority considerations with the goal of protecting customers that need to conduct on-site electrical work as part of renovations and expansions of manufacturing plants and buildings.
Model PD3129 is a non-contact phase rotation meter that detects the phase of electrical current flow within insulated wires without using metallic contact voltage clips. The green arrow indicates the normal phase, which can be useful for visual reports that document the proper completion of electrical work.
Key Features: Hioki PD3129 PHASE DETECTOR
- Simply clip clamps onto wire insulation
- Green LED arrow clearly shows phase direction, perfect for visual reports
- Rotating LED indicator shows the phase sequence for a 3-phase power supply at a glance
- Intermittent beeps signal positive phase; continuous tone signals reverse phase
- Magnetic base allows the instrument to be secured on a distribution panel
Specifications: Hioki PD3129 PHASE DETECTOR
| Functions | Phase detection (positive and negative) |
|---|---|
| Voltage detection method | Static induction |
| Voltage range | 70 to 600 V AC (50/60 Hz) (sine wave,continuous input) |
| Frequency range | 45 Hz to 66 Hz |
| Object to be connected | 2.4 mm (0.09 in) to 17 mm (0.67 in) of insulated wiring |
| Display | Phase detection :Positive ; 4 LEDs lit in clockwise order and the buzzer sounds intermittently, green arrow lights up Negative ; 4 LEDs lit in counterclockwise order and the buzzer sounds continuously |
| Battery check function | Power ON lamp: lights up (Power ON), blinks (Battery LOW) |
| Auto power off | Auto shut off if no activity is detected after power is turned ON for 15 minutes |
| Power supply | R6P (AA) manganese battery ×2, Continuous use: 70 hr |
| Dimensions and mass | 70 mm (2.76 in)W × 75 mm (2.95 in)H × 30 mm (1.18 in)D, 200 g (7.1 oz), Cord length : 0.7 m (2.30 ft) |
Includes: Hioki PD3129 PHASE DETECTOR
- Hioki PD3129 PHASE DETECTOR
Accessories: Hioki PD3129 PHASE DETECTOR
| Accessories | Carrying case ×1, Strap ×1, Spiral tube ×1, Instruction manual ×1, R6P (AA) manganese battery ×2 |
|---|
