Hioki IR4017 ANALOG MΩ HiTESTER:
Hioki insulation testers or megohmmeters feature all-in-one designs including built-in rugged cases and test lead storage compartments. The IR4017-20 is a single-range, 500V/1000MΩ analogue insulation resistance tester with efficient functions and features to help shorten work time associated with field insulation testing.
Are you trying to find good, insulation testers? Yes, this is the perfect moment and place for you. Tools Bangladesh is offering testing supplies and tools in Bangladesh. As a result, You could be able to purchase the desired tool from us in Bangladesh with the most affordable price and delivery options.
Key Features:
- Single range testing voltage of 500 V
- Test insulation resistance up to 1000 MΩ
- Built tough to withstand a 1-meter drop onto a concrete floor
- Bright LED luminous scale
- Check for live circuits and battery status
- Integrated hard case for quick and easy storage without disconnecting the leads
Specifications:
Accuracy guaranteed: 1 year
| Rated output voltage |
500 V DC |
| Effective maximum indicated value |
1000 MΩ |
| Accuracy 1st effective measuring range |
±2 % of scale length, 1 M to 500 MΩ |
| Lower limit resistance |
0.5 MΩ (measurement resistance value to maintain testing voltage) |
| Overload protection |
600 V AC (10 sec.) |
| AC voltage range |
0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy,
500 kΩ or more input resistance |
| Other functions |
Bright LED luminous scale, Drop proof (on concrete, 1 m/1 time), Battery check, Live circuit check, Auto discharge |
| Power supply |
LR6 (AA) alkaline batteries ×4, Continuous use: 20 hours (no load) |
| Dimensions and mass |
159 mm (6.26 in) W × 177 mm (6.97 in) H × 53 mm (2.09 in) D, 610 g (21.5 oz), (including battery, excluding test lead) |
| Included accessories |
Test Lead L9787 ×1, LR6 (AA) alkaline batteries ×4, Instruction manual ×1, Shoulder strap ×1 |
