HIOKI AC, DC CURRENT PROBE CT6845A

Home › Hioki
Thumbnail
Shop : Tools Bangladesh
Product ID : 4325
Brand : Hioki
Availability : Out of Stock
Price BDT : Ask for Price
Reviews :
Share :
Request Quote

  • Customer Support

    +8801965656380

  • Cash One Delivery

    Pay after getting the product on hand

  • Warranty

    1 Year warranty by manufacturer

  • Secured Payment Method

    Your cart is always secure to shop

  • Easy Return Policy

    24 hours return without physical defect.

Hioki's clamp type AC/DC current sensors can be connected directly to Hioki Power Analyzers and Memory HiCorders. Also, it can be connected to Power Meters, Oscilloscopes, DMMs, etc. by using an optional sensor unit.

HIOKI AC, DC CURRENT PROBE CT6845A Price in Bangladesh reflects its premium quality and advanced measuring capabilities. Designed for precision testing, this probe supports a wide frequency range and offers high accuracy in both AC and DC current measurements. Ideal for power analysis, automotive testing, and inverter development, the CT6845A ensures stable performance in demanding environments. Its compact design and superior noise resistance make it suitable for professional applications. HIOKI’s trusted engineering and robust build quality ensure long-term reliability. For professionals seeking accurate results, the HIOKI AC, DC CURRENT PROBE CT6845A Price in Bangladesh justifies the investment in precision and durability.

Key Features

  • Frequency bandwidth DC to 200 kHz
  • Rated current 500 A AC/DC
  • Power supplied via the measurement instrument (when connecting Hioki Power Analyzer or Memory HiCorder)
  • Ideal for use in environmental testing with broad -40°C to 85°C temperature range
  • Ideal for EV inverter evaluation and PV power generation PCS evaluation
  • Single-handed operation and robust locking mechanism

Basic specifications

Accuracy guaranteed: 1 year

Rated current 500 A AC/DC
Frequency bandwidth DC to 200 kHz
Diameter of measurable conductors Max. φ 50 mm (1.97 in.)
Max. allowable input ±1500 A peak
(Within 20 ms in an environment of 40°C/104°F or less)
Output voltage 4 mV/A
Output resistance 50 Ω ± 10 Ω
Accuracy (amplitude)
±(% of reading + % of full scale)		 DC: 0.2% + 0.02%
DC < f ≤ 100 Hz: 0.2% + 0.01%
Linearity ±20 ppm Typical
Common-Mode Voltage Rejection Ratio
(CMRR)		 DC to 1 kHz：150 dB or greater
1 kHz to 10kHz：130 dB or greater
10 kHz to 100 kHz：100 dB or greater
(effect on output voltage and common mode voltage)
Automatic phase correction Automatically performs phase correction when connected to PW8001
Operating temperature, humidity -40°C to 85°C (-40°F to 185°F), 80% RH or less
Standards Safety IEC 61010 Type D
EMC IEC 61326
Withstand voltage AC 4260 V
Power supply Power suppled via the Power Analyzer PW8001, PW6001, PW3390, Sensor Unit CT9555, CT9556, CT9557, or 3CH CURRENT UNIT U8977
Max. rated power 7 VA or less (When measuring 500 A/55 Hz with ±12 V power supply)
Dimensions and mass Approx. 238 mm W × 116 mm H × 35 mm D
(approx. 9.37 in. W × 4.57 in. H × 1.38 in. D), 860 g (30.3 oz.)
Cable length Approx. 3 m (9.84 ft.)
Included accessories Markup bands ×6, Carrying Case, Instruction Manual
Included accessories Markup bands ×6, Carrying Case, Instruction Manual
Included accessories Markup bands ×6, Carrying Case, Instruction Manual

Hioki's clamp type AC/DC current sensors can be connected directly to Hioki Power Analyzers and Memory HiCorders. Also, it can be connected to Power Meters, Oscilloscopes, DMMs, etc. by using an optional sensor unit.

HIOKI AC, DC CURRENT PROBE CT6845A Price in Bangladesh reflects its premium quality and advanced measuring capabilities. Designed for precision testing, this probe supports a wide frequency range and offers high accuracy in both AC and DC current measurements. Ideal for power analysis, automotive testing, and inverter development, the CT6845A ensures stable performance in demanding environments. Its compact design and superior noise resistance make it suitable for professional applications. HIOKI’s trusted engineering and robust build quality ensure long-term reliability. For professionals seeking accurate results, the HIOKI AC, DC CURRENT PROBE CT6845A Price in Bangladesh justifies the investment in precision and durability.

Key Features

  • Frequency bandwidth DC to 200 kHz
  • Rated current 500 A AC/DC
  • Power supplied via the measurement instrument (when connecting Hioki Power Analyzer or Memory HiCorder)
  • Ideal for use in environmental testing with broad -40°C to 85°C temperature range
  • Ideal for EV inverter evaluation and PV power generation PCS evaluation
  • Single-handed operation and robust locking mechanism

Basic specifications

Accuracy guaranteed: 1 year

Rated current 500 A AC/DC
Frequency bandwidth DC to 200 kHz
Diameter of measurable conductors Max. φ 50 mm (1.97 in.)
Max. allowable input ±1500 A peak
(Within 20 ms in an environment of 40°C/104°F or less)
Output voltage 4 mV/A
Output resistance 50 Ω ± 10 Ω
Accuracy (amplitude)
±(% of reading + % of full scale)		 DC: 0.2% + 0.02%
DC < f ≤ 100 Hz: 0.2% + 0.01%
Linearity ±20 ppm Typical
Common-Mode Voltage Rejection Ratio
(CMRR)		 DC to 1 kHz：150 dB or greater
1 kHz to 10kHz：130 dB or greater
10 kHz to 100 kHz：100 dB or greater
(effect on output voltage and common mode voltage)
Automatic phase correction Automatically performs phase correction when connected to PW8001
Operating temperature, humidity -40°C to 85°C (-40°F to 185°F), 80% RH or less
Standards Safety IEC 61010 Type D
EMC IEC 61326
Withstand voltage AC 4260 V
Power supply Power suppled via the Power Analyzer PW8001, PW6001, PW3390, Sensor Unit CT9555, CT9556, CT9557, or 3CH CURRENT UNIT U8977
Max. rated power 7 VA or less (When measuring 500 A/55 Hz with ±12 V power supply)
Dimensions and mass Approx. 238 mm W × 116 mm H × 35 mm D
(approx. 9.37 in. W × 4.57 in. H × 1.38 in. D), 860 g (30.3 oz.)
Cable length Approx. 3 m (9.84 ft.)
Included accessories Markup bands ×6, Carrying Case, Instruction Manual

Included accessories Markup bands ×6, Carrying Case, Instruction Manual

Included accessories Markup bands ×6, Carrying Case, Instruction Manual
