Model: Fluke 1662 Multifunction Testers
Fluke 1662 Multifunction Installation Tester is A solid, reliable, basic installation tester Test voltage and frequency. This is the best tool for all features.
Fluke 1662 Multifunction Installation Tester delivers hermetic, basic installation study features
The Fluke 1662 installation tester gives you Fluke reliability and all the basic investigation accomplish you compulsion for daylight-in, hours of day-out installation examine. It tests all local regulations and is easy and intuitive to use.
Additional helpful features taking into consideration the On/Off switchable auto-begin for RCD and loop test, and self-exam save times and have enough maintenance you more confidence in your results.
Iconic Engineering is a trusted distributor of electronic instruments. You should never take any type of instrument until you know about the distributor and that are providing where are from.
Key features: Fluke 1662 Multifunction Testers
A solid, reliable, basic installation tester
- Tests voltage and frequency
- Checks wiring polarity to detect broken N wires
- Measures insulation resistance and loop and line resistance
- Measures motor windings with continuity test
- Calculates prospective earth fault current (PEFC/IK) and prospective short-circuit current (PSC/IK)
Specifications: Fluke 1662 Multifunction Testers
| AC voltage measurement |
| Range |
500 V |
| Resolution |
0.1 V |
| Accuracy 45 Hz – 66 Hz |
0.8% + 3 |
| Input impedance |
360 kΩ |
| Overload protection |
660 V rms |
| Continuity testing (RLO) |
| Range (autoranging) |
20 Ω / 200 Ω / 2000 Ω |
| Resolution |
0.01 Ω / 0.1 Ω / 1 Ω |
| Open Circuit Voltage |
>4 V |
| Insulation resistance measurement (RISO) |
| Accuracy of tTest voltage (at rated test current) |
+10%, -0% |
| Test voltage |
100 V
250 V
500 V
1000 V |
| Insulation resistance range |
20 MΩ / 50 MΩ
20 MΩ / 100 MΩ
20 MΩ / 200 MΩ
20 MΩ / 200 MΩ / 500 MΩ
20 MΩ / 200 MΩ / 1000 MΩ |
| Resolution |
0.01 MΩ / 0.1 MΩ
0.01 MΩ / 0.1 MΩ
0.01 MΩ / 0.1 MΩ
0.01 MΩ / 0.1 MΩ / 1 MΩ
0.01 MΩ / 0.1 MΩ / 1 MΩ |
| Test current |
1 mA @ 50 kΩ
1 mA @ 100 kΩ
1 mA @ 250 kΩ
1 mA @ 500 kΩ
1 mA @ 1 MΩ |
| Loop and line impedance (ZI) |
| Range |
10 Ω / 0.001 Ω / High current mΩ mode |
| Resolution |
0.01 Ω / 0.1 Ω / 1 Ω |
| Prospective earth fault current, PSC test |
| Range |
1000 A / 10 kA (50 kA) |
| Resolution |
1 A / 0.1 kA |
| Computation |
Prospective earth fault current (PEFC) or Prospective short circuit current (PSC) determined by dividing measured mains voltage by measured loop (L-PE) resistance or line (L-N) resistance, respectively. |
| RCD testing, RCD types tested |
| RCD Type |
A4, AC¹, G², S³ |
| Notes |
¹Responds to AC
²General, no delay
³Time delay
4Responds to pulsed signal
5Responds to smooth DC signal |
| Tripping speed test (ΔT) |
| Current settings¹ |
10-30-100-300-500-1000 mA – VAR
10-30-100 mA |
| Multiplier |
x ½, x 1
x 5 |
| Measurement range |
RCD Type G |
310 ms
50 ms |
| RCD Type S |
510 ms
160 ms |
| Notes |
¹1000 mA type AC only
700 mA maximum type A in VAR mode
VAR mode not available for type B. |
| RCD/FI-Tripping Current Measurement/Ramp Test (IΔN) |
| Current range |
30% to 110% of RCD rated current¹ |
| Step size |
10% of IΔN² |
| Dwell time |
Type G |
300 ms/step |
| Type S |
500 ms/step |
| Measurement accuracy |
±5% |
| Specified trip current ranges (EN 61008-1) |
50% to 100% for Type AC
35% to 140% for Type A (>10 mA)
35% to 200% for Type A (≤10 mA)
50% to 200% for Type B
²5% for Type B |
| Notes |
¹30% to 150% for Type A IΔN > 10 mA
30% to 210% for Type A IΔN = 10 mA
20% to 210% for Type B |
| Phase Sequence Indication |
| Icon |
 Phase Sequence indicator is active. |
| General Specifications |
| Size (L x W x H) |
10 x 25 x 12.5 cm |
| Weight (incl. batteries) |
1.3 Kg |
| Battery size, quantity |
Type AA, 6 ea. |
| Sealing |
IP-40 |
| Safety |
Complies with EN61010-1 Ed 2.0 (2001-02), UL61010, ANSI/ISA –s82.02.01 2000 and CAN/CSA c22.2 No. 1010 2nd edition |
| Overvoltage |
CAT III / 500V; CAT IV 300V |
| Performance |
EN61557-1 to EN61557-7 Second Edition and EN61557-10 Second Edition |
Includes: Fluke 1662 Multifunction Testers
- 6x AA (IEC LR6) cell batteries
- C1600 hard carrying case
- Zero adapter
- Heavy-duty mains cord
- STD standard test lead set
- C1600 hard carrying case
- Padded carrying and waist strap
- Quick reference guide
- TP165X remote control probe and lead
- User's manual on CD-ROM
