Model: Amprobe TMA10A Anemometer
The Amprobe TMA10A Anemometer with Flexible Precision Vane is ideal for HVAC/R technicians measuring heating, ventilation, air-conditioning, refrigeration, wind flow and temperature in residential, commercial and industrial air conditioning systems.
It offers numerous functions—use it to check air velocity FPM (feet per minute), air volume (flow) CFM (Cubic feet per minute) plus the remote vane allows greater measurement location flexibility.
Switch between °C and °F. Input the area of airflow measurement to gain accurate air velocity results. Measure an airflow source for a continuous moving average for up to two hours. Determine minimum, maximum and average readings from a single point air source.
Tools Bangladesh is the best site to keep trust here and we have the distributor of Amprobe. Order now to get quick delivery.
Key Features: Amprobe TMA10A Anemometer
- Measure air velocity or airflow
- RS232 interface output with optional software and cable, TM-SWA
- The continuous moving average for up to 2 hours
- MIN/MAX/AVG reading on a single point
- Air Velocity average for multiple points
- Data Hold to freeze measurement display of both readings
- Auto power-off function
- Obtain airflow (CFM) average for multi-point
Specifications: Amprobe TMA10A Anemometer
| Air velocity |
0.40 → 25.00 m/s |
+/- 2% of full scale |
| 125 → 4900 ft/min |
+/- 2% of full scale |
| Air flow |
0.01 → 99.99 m3/sec |
0 → 9.999 m |
| 1 ft → 9999 cfm |
0 → 9.999 ft |
| Air temperature °F (°C) |
32 °F → 122 °F (0 °C to 50 °C) |
+/- 1.5 °F (0.8 °C) |
| Specifications |
| Display: |
Dual 4-digit (9999 count) LCD |
| Operating temperature: |
32 °F to 122 °F (0 °C to 50 °C) |
| Operating humidity: |
Max. 80 % RH |
| Power supply: |
9 V battery (heavy-duty alkaline) |
Includes: Amprobe TMA10A Anemometer
| |
Description |
| |
- Measure CFM by inputting the vent dimensions
- Obtain air flow average by taking up to eight data points
- Vane has three-foot cord for measurement flexibility
- Deluxe carrying case
|
Accessories: Amprobe TMA10A Anemometer
- Carrying case,
- batteries (installed) users manual,
- optional PC interface for charting or analysis
