HIOKI AC, DC CURRENT SENSOR CT7822 Price in Bangladesh offers exceptional accuracy and reliability for measuring AC and DC currents in industrial and electrical applications. This advanced sensor features a compact design and high sensitivity, making it ideal for precise current monitoring and analysis. Its robust build ensures durability even in harsh environments. Customers in Bangladesh can benefit from competitive pricing without compromising quality. The HIOKI CT7822 sensor supports efficient energy management and safety compliance, making it a top choice for professionals. Discover the best HIOKI AC, DC CURRENT SENSOR CT7822 Price in Bangladesh through trusted local suppliers and authorized dealers.
Key Feature
- Exceptional performance in a compact package
- Easy to install in confined locations with complex wiring
- Rated current: 20 A AC/DC
Basic specifications
Accuracy guaranteed: 1 year
| Rated measurement current |
20 A AC/DC |
| Max. allowable input |
30 A rms continuous (±43 Ap) |
| Bandwidth |
DC to 100 kHz |
| Basic accuracy |
DC± 0.3％ rdg. ±0.1％ f.s. |
| Core diameter |
φ 5 mm or less |
| Output connectors |
HIOKI PL 14 |
| Operating temperature range |
Sensor: -40°C to 85°C, 80% RH or less (non-condensing)
Relay box: -25°C to 50°C, 80% RH or less (non-condensing) |
| Dimensions |
Sensor: 76.5W × 23.4H ×14.2D mm (excluding protrusions and the cable)
Relay box: 80W × 20H × 26.5D mm (excluding protrusions and the cable) |
| Weight |
140 g |
| Output cable length |
4 m (between sensor and relay box), 0.2 m (between relay box and output connector) |
| Included accessories |
Colored labels (for channel identification), Carrying case, Instruction Manual, Operating Precautions |
| Included accessories |
Colored labels (for channel identification), Carrying case, Instruction Manual, Operating Precautions |
| Included accessories |
Colored labels (for channel identification), Carrying case, Instruction Manual, Operating Precautions |
