Product overview: Fluke 5622 Thermistor Probe | Precision Temperature

The Fluke Calibration series of fast response PRTs includes four models with stainless steel sheaths ranging from 0.5 to 3.2 mm (0.02 to 0.125 in) in diameter. Because these high-quality wire-wound sensors come in small packages, heat transfer to the sensors occurs quickly. Time constants from 0 °C to 100 °C are as fast as 0.4 seconds.

Immersion requirements for these probes is also a plus, ranging from just 10 mm to 64 mm (0.4 to 2.5 inch), depending on the model. Getting into shallow or tight places is not a problem. And because these probes can handle temperatures from –200 °C to 350 °C, they’re more versatile than most thermistors.

5622 PRTs come with a Model 1923-4-N ITS-90 Comparison Calibration, which includes seven points from –197 °C to 300 °C. Short-term accuracies are achieved as good as ±0.04 °C at 0 °C.

Readout options for the Model 5622 PRTs include Fluke Calibration's 1523 Handheld Thermometers, 1524 Handheld Thermometers or the 1529 Benchtop Thermometer. 5622's purchased with a 1523/1524 will have the calibration coefficients programmed into the probe's smart connector.

Whatever your thermometry requirements are, come to Fluke Calibration. No one else offers a wider range of standards-quality reference thermometers.

Key Features

  • Time constants as fast as 0.4 seconds.
  • NVLAP-accredited calibration, lab code 200348-0.
  • Small diameters ranging from 0.5 mm to 3.2 mm.
  • Ideal special temperature measurement applications requiring fast response or short immersion over a wide temperature range.

Specifications: Fluke 5622 Thermistor Probe | Precision Temperature

Specifications
Temperature Range  –200 °C to 350 °C
Nominal RTPW  100 Ω
Temperature Coefficient 0.00385 Ω /Ω/°C nominal
Calibrated Probe Accuracy (includes calibration uncertainty and short-term stability)  5622-05 and 5622-10:
± 0.04 °C at  –200 °C
± 0.04 °C at 0 °C
± 0.09 °C at 200 °C
± 0.09 °C at 300 °C

5622-16 and 5622-32:
± 0.04 °C at  –200 °C
± 0.04 °C at 0 °C
± 0.045 °C at 200 °C
± 0.055 °C at 300 °C
Time Constant
(63.2 %) 		 From 0 °C to 100 °C:
5622-05: 0.4 seconds
5622-10: 1.5 seconds
5622-16: 3.0 seconds
5622-32: 10 seconds (90 %)
Immersion Depth  5622-05: 10 mm (0.4 in)
5622-10: 20 mm (0.8 in)
5622-16: 32 mm (1.25 in)
5622-32: 64 mm (2.5 in)
Thermal EMF  20 mV at 350 °C
Sheath  316 SST
5622-05: 100 x 0.5 mm (4 x 0.02 in)
5622-10: 100 x 1.0 mm (4 x 0.04 in)
5622-16: 200 x 1.6 mm (8 x 0.06 in)
5622-32: 200 x 3.2 mm (8 x 0.13 in)
Cable  PVC, 4-wire cable, 2 meters long, 90 °C max temp

N/A

N/A
