The LX 100 luxmeter is meant to be used in sport installations, workstations, offices, parking, and flyer centers. The LX 100 has a measuring range from 0,1 to 150 000 lux and is supplied gone than a calibration authorize.
This luxmeter has a timed measurement feature, and gives minimum, maximum, and average values. Unrepresentative illuminance is eliminated by the pause appear in, and illuminance is displayed for local measurements. Quantification of a lustrous contribution is ended by making a relative measurement to a mention intend. The sensing element is a silicon phtodiode, behind spectral responsiveness in accordance when the photonic curve CIE.
Key Features: Lutron LX 100 LUX METER
- Sensing element contained within a silicon photodiode - spectral responsivity compliance w/ photonic curve (CIE)
- Illuminance measurements in lux or foot candelas under 10 lux, with 0.1 lux accuracy & 1 percent accuracy above until 150,000 lux
- Instantaneous measurements displays illuminance for local measurements
- Timed measurements
- Illuminance - min / max value display
- Illuminance - averaged value calculations
- Relative illuminance function
- Enables relative measurement to reference point for quantification of luminous contribution or illuminance decrease
- Hold function
- Avoids illuminance noise
- Save local measurement on screen
- Measurements are saved when an unexpected power interruption occurs
Specifications: Lutron LX 100 LUX METER
|
Measuring range
|
from 0,1 to 150 000 Lux
from 0.01 to 13940 fc
|
|
Spectral response
|
as per standard photopic curve
V(?) NF C 42 -710 class C.
|
|
Error limit V (f1)
|
< 10%
|
|
True cosine evaluation (f2)
|
< 6%
|
|
Linearity (f3)
|
< 3%
|
|
Measurement capability
|
3 days – 03D00H00M
|
|
Display.
|
Backlit LCD graphic 128x64.
|
|
Working temperature
|
from 0°C to +50°C
|
|
Storage temperature
|
from 0°C to +50°C
|
|
Housing dimensions (without sensor)
|
120x58x34 mm
|
|
Weight (housing+sensor+battery)
|
185 gr
|
|
Digital electronic
|
low drift
|
|
Mini-USB plug
|
for USB power supply adaptor
|
|
Power supply
|
3 batteries 1.5V type LR3-AAA
|
|
Battery life
|
72 hours min, continuous operation.
|
|
Electromagnetic compatibility
|
according to 89/336/CEE
|
|
Conformity.
|
as per RoHS
|
